LS ELECTRIC SV0037IS7-4NO LS iG5A Drive With Good Price In Stock


High Torque Performance and Precise VFD Inverter featuring on strong torque performance and accurate control for general use iS7 generates more powerful performance in terms of V/F control, V/F PG, slip compensation, sensorless vector control, PMSM (Permanent Magnetic Synchronous Motor) and focuses on user-friendly interface and environment-friendly features including wide graphic LCD keypad, user & macro group support, electro-thermal functions for motor protection, protection for input/output phase Open.

  • Constant torque / Variable torque dual rating

  • Selectable V/f, V/f PG, sensorless vector, sensored vector

  • 150 MIPS(million instructions per second) high speed DSP

  • Easy to control: Easy Start Mode, User & Macro group, Multi Function Key

  • 2nd motor sensorless control and parameter setting

  • Available IP54 enclosure(0.75~22kW[1~30HP]) as built-in option*

  • Built-in RS485(LS Bus / Modbus RTU) communication

  • Built-in Dynamic braking transistor (0.75~22kW[1~30HP])

  • Available EMC Filter & DC Reactor as built-in option EMC Filter(0.75~22kW[1~30HP]) / DC Reactor(0.75~160kW[1~215HP])

  • Wide graphic LCD keypad (6 different languages)

  • PLC board (optional): Master-K platform: 14 max. inputs & 7 max. outputs

  • Extension I/O boards (Optional): 11 max. inputs & 6 max outputs

  • Communication boards (Optional): Profibus-DP, DeviceNet, Modbus TCP, Rnet, LonWorks, CANopen

  • Monitoring & commissioning PC based software tool (Drive View)


Technical Specification
Manufacturer: LS
Series: iS7
Model: SV0037iS7-4NO
Product Code: 6121001900
Application: general purpose
Capacity, kW: 3.7
Current, А: 8
Main power supply, V: 380-480
Phase: 3
Output frequency, Hz: 0,01-400
Enclosure: IP21
Overload capacity, % per 1 min.: 150
EMC filter: optional
Braking unit: +
Analog input: -
Digital input: 8
Analog output: 1
Digital output: -
Relay output: -
RS485 (Modbus RTU): RS485, Modbus RTU (optional: Profibus-DP, DeviceNet, Modbus TCP, Rnet, LonWorks, CANopen)
PID: PID-Regulation
V/f control mode: +
Vector control with feedback: optional
Sensorless vector control: +
Operation temperature, °С: -10.....+50
Storage temperature, °С: -20.....+65
Dimensions (W x H x D), mm: 150х284х200
Weight, kg: 4,5


  • image

  • image

  • image

  • image

LS ELECTRIC SV0037IS7-4NO LS iG5A Drive With Good Price In Stock


Model range


iS7 general industrial series (3 phase 200-230 V)

SV0008IS7-2NOFD

SV0015IS7-2NOFD

SV0022IS7-2NOFD

SV0037IS7-2NOFD

SV0055iS7-2NOFD

SV0075iS7-2NOFD

SV0110iS7-2NOFD

SV0150iS7-2NOFD

SV0185iS7-2NOFD

SV0220iS7-2NOFD

SV0300iS7-2SO

SV0370iS7-2SO

SV0450iS7-2SO

SV0550iS7-2SO

SV0750iS7-2SO


iS7 general industrial series (3 phase 380-480 V)

SV0008iS7-4NO

SV0015iS7-4NO

SV0022iS7-4NO

SV0037iS7-4NO

SV0055iS7-4NO

SV0075iS7-4NO

SV0110iS7-4NO

SV0150iS7-4NO

SV0185iS7-4NO

SV0220iS7-4NO

SV0300iS7-4NO

SV0370iS7-4NO

SV0450iS7-4NO

SV0550iS7-4NO

SV0750iS7-4NO

SV0900iS7-4SOD

SV1100iS7-4SOD

SV1320iS7-4SOD

SV1600iS7-4SOD

SV1850iS7-4SOD

SV2200iS7-4SOD

SV2800iS7-4SO

SV3150iS7-4SO

SV3750iS7-4SO
