White Color 12V LED Marquee Letters Modules 5054 Backlight For DC12V Office Wall Sign Advertising Signage

12V 3D Printed LED Marquee Letters Modules 5054 Backlight For DC12V Office Wall Sign Advertising Signage

Specifications:


Pictures:



Feature:

1.SMT with Taiwan chip. The products are in high luminous, and more stable compared with others usual leds.

2.Compared with traditional lights,LED light comes with more energy saving, environmental friendly, long lifespan, Stable well, install conveniently, ect.

3.Monocolour achieve the effect of advertising signs staying one color, fullcolor string suitable for colorchanging advertising sign , It makes outdoor marquee letters produced easily and beautiful appearance.

4.Suitable for different material board like Aluminum substrate , stainless steel plate,ect. install conveniently.

5.Every piece is series connected . If one is down, Just need to exchange the broken one. Much better than the kind that need to exchange the whole roll string if there is only 1 pcs gone down.

6.Flexible enough for installation, high strength, High temperature resistance,anti ultraviolet, aging-resistant, Waterproof IP67.


Driver select and installation:

1.Total load power of the driver should not be over than 80% of the driver rated power.
For example: Driver output:DC5V,40A, Rated power is 200W. the load power should not be over
Than 200*80%=160W. If every pcs light is 0.8W, Then the quantity should not be over than
160/0.1=200pcs.

 2.If there is more than one driver, Pls make sure that there is no return circuit.Otherwise the drivers will be burned out.

3.Connect ways: When connect the string with driver, pls keep the beging and the end connected with the main wire . and main wire must be 2.5 mm2 .

Application pictures:
LED module is widely used for all kinds of

LED channel letters,

Name board,

3D led marquee letters



Notice:
1.Pls confirm the dirver is DC12V output.

2.The wire connected with driver shouldn’t be less than 2.5 mm2,If the quantity is big,the wire should be more thicker.

3.Pls make sure of the positive and negative of the string, usually the negative is white.

• 1year warranty, life-long maintenance. Answer will be replied in 24hours.

• Technican will solve the problem on site.

• Give product upgrade solution to improve plane.

• We will give phone call interviews every month during warranty period
