Low cost modern multi-storey prefab light steel structure factory workshop building:
Product description:
Low cost modern multi-storey prefab light steel structure factory workshop building is a new type of building structure system. The main steel frame is formed by linking up H section, Z section and U section steel components while roof and wall using a variety of panels and other components such as windows, doors, and cranes.
Product application:
Low cost modern multi-storey prefab light steel structure factory workshop building is widely used as industry factory building, warehouse, gymnasium, poultry shed, school and medical clinic, etc.
2. Specification
|
Items |
Specification | |
| Main Steel Frame | Column | Q235, Q355 Welded H Section Steel |
| Beam | Q235, Q355 Welded H Section Steel | |
| Secondary Frame | Purlin | Q235 C and Z purlin |
| Knee brace | Q235 Angle Steel | |
| Tie Rod | Q235 Circular Steel Pipe | |
| Brace | Q235 Round Bar | |
| Vertical and Horizontal Support | Q235 Angle Steel, Round Bar or Steel Pipe | |
| Maintenance system | Roof Panel |
EPS Sandwich Panel /Glass Fiber Sandwich Panel / Rock Wool Sandwich Panel / PU Sandwich Panel /Steel Sheet |
| Wall Panel | Sandwich Panel / Corrugated Steel Sheet | |
| Accessories | Window | Aluminiumn Alloy Window / PVC Window / Sandwich Panel Window |
| Door | Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door | |
| Rainspout | PVC | |
| Live load on Roof | In 120kg/Sqm (Color steel panel surrounded) | |
| Wind Resistance Grade | 12 Grades | |
| Earthquake-resistance | 8 Grades | |
| Structure Usage | Up to 50 years | |
| Temperature | Suitable temperature: -50°C~+50°C | |
| Certification | ISO9001:2008, ISO14001:2004 | |
| Finishing Options | Vast array of colors and textures available | |
| Paint Options |
Alkyd painting, twice primary painting, twice finish painting (grey paint, red paint, white paint, epoxy zinc, etc.) Or hot galvanized. |
|
3. Characteristics
1). Different types and sizes according to customer's needs, large or small, wide span: single span or multiple spans, the max span is 36m without middle column.
2). Low cost and maintenance: unit price range from USD30/m2 to USD70/m2 according to customers request.
3). Fast construction and easy installation: time saving and labor saving, all the items are factory made, pre-cut, pre-welded, pre-drilled, pre-painted.
4). Reduced construction waste, long using lifespan: up to 50 years.
5). Nice appearance.
6). Others: environmental protection, stable structure, high quake-proof, water proof and fire proof, and energy conserving.
1. Some main oversea projects we undertook in the last couple months
Industrial factory (13000M2) ---Peru
Warehouse (14000M2)----Republic of Uzbekistan
Workshop (12000M2)----Brazil
Warehouse (3600M2)---France
Vegetable market (2500M2)----Mauritius
Pig shed (3500M2)---Australia
Chicken shed (2800M2)---Philippines
Aircraft hangar (1300M2)-----Maldives
Warehouse (900M2)----Russia
Prefabricated house (70M2)----800sets---Angola
Container house (20')----60 sets South Africa
2. Transaction history
