Which is painted steel plate with organic coating. It is divided into single board, sandwich panel and floor board and so on.
It is widely used in the metope and roof of large steel sructure buildings, Prefab house, and integrated houses.
| Product Name | Steel Plate Prepainted Color Galvanized Steel Coil Corrugated Roofing Sheet |
| Sheet material: | Q235B,Q345B |
| Thickness: | 0.3-0.6mm |
| Width: | 600mm-1250mm |
| Length: | According to the customer |
| Zinc coating: | 40g/sqm-220g/sqm |
| Color: | Blue, red, green, yellow, and any other colors |
| Standard: | GB |
| Application: | Used for roofing |
| Available model: |
YX35-125-750(V-125), YX30-160-800, YX25-205-820, YX25-210-840, YX15-225-900, YX10-113-910 |
Our factory have independent design institute and the Design qualification is top grade.
We have excellent design and the perfect price Beyond your imagination.
If you want to a perfect warehouse and please provide to us that information as follows:
1. Location (where will be built? ) _____country, area
2. Size: Length*width*height _____mm*_____mm*_____mm
3. Wind load (max. Wind speed) _____kn/m2, _____km/h, _____m/s
4. Snow load (max. Snow height)_____kn/m2, _____mm
5. Anti-earthquake _____level
6. Brickwall needed or not If yes, 1.2m high or 1.5m high
7. Thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; If not, the metal steel sheets will be ok. The cost of the latter will be much lower than that of the former.
8. Door quantity & size _____units, _____(width)mm*_____(height)mm
9. Window quanity & size _____units, _____(width)mm*_____(height)mm
10. Crane needed or not If yes, _____units, max. Lifting weight____tons; Max. Lifting height _____m
Q1: What are your main products?
A: Our man products have prefab K house, T house, SHS house, H house, container house, light steel structure villa, steel structure warehouse, sentry box, sandwich panel and other constructive materials.
Q2: What will client provide before factory offers good quotation?
A: When we receive inquiry from client, client please fills purchasing intention sheet, providing us with information of house dimensions, draft drawing, layout and materials for prefabricated house. We will design the drawings and offer competitive quotation with the above information.
Q3: What are main materials of prefabricated house?
A: Our prefabricated house materials mainly include light steel structure, sandwich panel, roof tile, door, window, covers, screws and other accessories.
Q4: What drawing of house will factory supply?
A: Plan drawing, elevation drawing, sectional drawing, foundation drawing, installation drawing.
Q5: How many colors do your steel plate have?
A: Offwhite, ivory white, blue, green and red color.
