BKNET-0102 Welded Pipe Eddy Current Flaw Detector
- 5000 Bag / Bags per Month
- T/T
Product Description
The technology of BKN originated from eddy current Laboratory of Institute of Materials, Nanjing University of Technology. At present, it is a leading high-tech enterprise specializing in developing types of NDT non-destructive testing instruments and equipment in China. As one of the non destructive testing equipment suppliers, the company is committed to the development of eddy current, ultrasonic, magnetic flux leakage and various non-standard equipment, holding independent research and development of a number of national patents.
Eddy current weld testing is the use of eddy current technology to test the welded pipe, this type of NDT testing is based on the premise of lossless. At the same time, we need to be clear that the welded pipe is, in general, the steel pipe that we usually say, which is a welded steel pipe.
Eddy current testing of welds is a non-destructive testing technique for detecting component defects by using the principle that the eddy current induced by the AC electromagnetic coil on the surface of the metal member encounters a defect. The oscillating current is generated in the conductive member by the excitation coil by the principle of electromagnetic induction, and the amount of change in the eddy current is measured by the detecting coil, thereby obtaining information on the component defect.
Eddy current weld inspection equipment is a non-destructive testing technique in which an alternating current electromagnetic coil induces eddy currents on the surface of a metal member. It is suitable for the detection of defects in conductive materials, including ferromagnetic and non-ferromagnetic metal materials.
BKNET-01\02 NDT weld testing equipment is used for on-line and off-line eddy current weld inspection. It has high sensitively to axial defects such as unwelded welding, dark spots and open cracks. In the production process, products are caused by welder failure. Slow and long-term injuries can be reliably detected.
BKNET-0102 Welded Pipe Eddy Current Flaw Detector performance
Detection channel | Double channel |
Detection speed | 1~500m/min(online) |
Frequency range | 100Hz-1MHz |
Gain | 0~99dB,step 0.1dB |
Phase rotation | 0-360 °step1 ° |
High pass | 0.1Hz~650Hz |
Low pass | 1Hz~10000Hz |
BKNET-0102 Eddy Current Weld Flaw Detector Features:
High precision end and end-to-tail signal removal
High precision real-time, delayed alarm output
Fast digital/analog electronic balance
Memory track delay blanking function
Non-equal amplitude phase/amplitude alarm domain
Remote automatic help system
Synchronous alarm output for internal and external clock control
