Description:
This RF power amplifier is suitable for all types of radio transmission, such as short-wave FM wireless remote control, FM radio station transmission, amateur radio 135-175MHz, 380-470MHz walkie-talkie and the like. The low-frequency input 2mW can output 2.5W maximum power, and the maximum output can be 2W at 500MHz. The minimum output can be 1.0W at 1000MHz. The amplifier housing has a heat dissipation function and can work stably for a long time.

Technical Parameters:
- Operating Frequency: 1-1000MHz
- Input Power: 2mW (3dBm)
- Output Power:
2.5W (34dBm) low frequency end (100MHz)
2.0W (33dBm) IF terminal (500MHz)
1.5W (31dBm) high frequency end (800MHz)
1.0W (30dBm) high frequency end (1000MHz)
- Working Voltage: 15V (DC)
- Operating Current: 430mA (Depends on the output power)
- RF Connector: Standard SMA Female
- Dimensions: 82*71*25mm (length * width * height)
- Product Weight: 90g

Package Included:
- 1 x RF Power Amplifier

Package: Normally we use the standard exporting packaging. We also can according to clients' request .

 Shipping :

1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier  we are co-operating at present.

2. By Air: Delivery from the Shanghai airport to customers’ destination city air port.

3. By Sea: Delivery from the Shanghai sea port .

Q1. Can I have a sample order?

A: Yes, we welcome sample order to test and check quality.

Q2. What about the lead time?

A: Samples arrived often need 3-5 days.

Q3. Do you have any MOQ (minimum order quality)limit?

A: Low MOQ, 1pc for sample checking is available.

Q4. How do you ship the goods and how long does it take to arrive?

A: We often ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping is also optional.

Q5. How to proceed an order?

A: Initially, let us know your requirements or application. Besides, We quote according to your requirements or our suggestions. Thirdly, customers confirms the samples and places deposit for formal order. Finally, We arrange the production.

Q6. Is it acceptable to print my logo on the product?

A: Yes. Please inform us formally before our product and confirm the design firstly based on our sample.

Q7: Do you offer guarantee for the products?

A: Yes, we offer one-year warranty for our products.

Q8: How to deal with the flaw?

A: Our products are produced in strict quality control system and the percent of pass is often maintained over 99.8%
