HY-1138A 21MP Camera 4K Video Record 1080P Industrial Microscope w/ 180X Lens USB Output 60LEDs

HY-1138A 21MP Camera 4K Video Record 1080P Industrial Microscope w/ 180X Lens USB Output 60LEDs

Features:
- 21MP CMOS sensor
- Support TF card to store image and video
- USB port supports measuring function
- Built-in adjustable crosshair set
- Adopted image sensor 1/2.33"
- Multi-language menu
- 1920x1080P@60fps
- 4K@30fps

Specifications:
- Image Sensor: 21MP CMOS Sensor
- Pixel Size: 1.335 x 1.335μm, 1/2.33"
- Frame Rate: 1920x1080@60fps H-D-M-I Output
- Photo Resolution: 1920x1080/30fps; 1280x720/30fps; 640x480/30fps; 320x240/30fps (MJPG)
- High Definition: Video record supports up to 4K
- Scanning Way: Scan line by line
- White Balance: Manual, automatic white balance
- Built-in Crosshair: Multiple colors available. 4 vertical and 4 horizontal movable lines
- Image Storage: USB port for PC; H-D-M-I port for TF card storage
- Video Port: H-D-M-I Port, USB Port (support measuring software)
- Exposure: Manual or Automatic Exposure
- Digital Magnification: 1X-10X digital zoom
- Operating Temperature: 0-60℃
- Power Supply: External connection 12V DC, enabling 10% deviation
- Lens: For C or CS connector
- Camera Ports: Standard H-D-M-I & USB port, TF card port and power supply port
- Menu Language: Multiple Languages, including English and Chinese

180X Lens:
- Optical Magnification: 0.7-4.5X
- Magnification Ratio: 1:6.5
- Compatible Main Lens Size: 45mm (Diameter)
- Working Distance: 100-120mm
- Min. Magnification: 0.7X with 120mm working distance & 18mm visual area
- Max. Magnification: 4.5X with 100mm working distance & 2-3mm visual area
- Photography Eyepiece: Standard 0.5X
- Auxiliary Objective Lens: None

Package Included:
- 1 x 21MP Industrial Camera
- 1 x 180X Adjustable Lens
- 1 x Adjustable Stand
- 1 x 60-LED Light Source
- 1 x H-D-M-I Cable
- 1 x USB Data Cable
- 1 x Disc (with measuring software)
- 1 x Remote Control

Note: Batteries are not included in the package.

Detail photo

FAQ

Q1. Can I have a sample order?

A: Yes, we welcome sample order to test and check quality.

Q2. What about the lead time?

A: Sample ususally take within 3 working days.

Q3. Do you have any MOQ (minimum order quality)limit?

A: For standard product, usually 1pcs/item. For the OEM order, MOQ at least 50pcs/item.

Q4. How to proceed an order?

A: After buyer confirm the product&price is ok and ready to buy, order will be please tell us your delivery address, phone number, sometimes need email. Then we can draft the order and it will have a alibaba paying link.

Q5. After paid, what info of the supplier provided?

A: Tracking number

Q6: Do you offer guarantee and after-service for the products?

A: Yes, 6- 12 months warranty for our products. Note: We will do not take the responsibility for Man-made damage or improper operation. Delivery demage will be negotiate.

Packing and Shipping

Package: Normally we use the standard paper package to export worldwide.

Shipping :

1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier  we are co-operating at present.

2. By chinese small parcel, usually for the customer to save the cost. But Chinese small parcel have the risk for lost parcel. Note: If we got the parcel back, we only can refund the item cost. If we didn't get the parcel,then sorry we can't refund any.

3. By Air: Delivery from the Shenzhen airport to customers’ destination city air port.

4. By Sea: Delivery from the Shenzhen sea port .
