Product Description
LD60-LM 60x60mm XYZ 3 Axis CNC Optical Manual Linear Slide Translation Stage Trimming Platform
Specification:
- Move direction:XYZ axis three degree of freedom
- Material:Aluminum
- The slider size:60mm x 60mm
- Stroke:XY axis ±6.5mm,Z axis 10mm
- Load: 29.4N (3kgf)
- Rail Type:V-type rail
- Minimum scale: 0.01mm
- Accuracy:0.01mm
- Net Weight:0.7kg
Features:
- It uses cross roller guide can achieve high precision,smooth movement.
- The main material for aluminum.Micrometer head driving.
- For precision movement,precise positioning, stable performance,easy installation and removal.
Applications:
1.DVD,MD,CD-related disc reading lens and writable optical head production and testing equipment.Mainly arcuate positioning platform.
2.LCD projector prism positioning and loading.
3.The optical fiber positioning,optical communication system products and testing equipment.
4.LCD production and testing equipment.
5.The semiconductor related production.equipment and testing equipment Evaluation.
Package Included:
- 1 x XYZ 3-Axis Linear stage
Size
