CNC Kit NewKer-110mm 1.2kw Low Noise High Torque Easy 3 Phase Servo Motor for 3D Printer Kit Cnc
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Government ministry/Bureau/Commission
Year Established:
2007
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
NewKer High Torque ac Servo Motor for Industrial Sewing Machine Similar Fanuc Cnc MotorNegotiableMOQ: 1 -
China Brand Best Price NEWKer ac 220v Servo Kit Cnc Servo Motor for Cnc Machine Three Phase or Single PhaseNegotiableMOQ: 1
-
High Precision 220v Servo Motor Gear Electric ac MotorNegotiableMOQ: 1
-
NEWKer 220V 1KW 4NM AC Servo Motor for Engraving Sewing Cnc Lathe MachineNegotiableMOQ: 1
-
Low Price NEWKer-CNC ac Motor 110-04030 Matched Cnc Controller Servo DriverNegotiableMOQ: 1
Poster
Products Description
PRODUCT:NewKer-110mm 1.2kw high torque easy servo motor for 3D Printer
110 Series of servo motorNewKer-110mm 1.2kw low noise high torque easy 3 phase servo motor for 3D PrinterNewKer-110mm 1.2kw low noise high torque easy 3 phase servo motor for 3D PrinterNewKer-110mm 1.2kw low noise high torque easy 3 phase servo motor for 3D PrinterNewKer-110mm 1.2kw low noise high torque easy 3 phase servo motor for 3D PrinterNewKer-110mm 1.2kw low noise high torque easy 3 phase servo motor for 3D PrinterNewKer-110mm 1.2kw low noise high torque easy 3 phase servo motor for 3D PrinterNewKer-110mm 1.2kw low noise high torque easy 3 phase servo motor for 3D PrintervNewKer-110mm 1.2kw low noise high torque easy 3 phase servo motor for 3D Printer2kw servomotor2kw servomotor 2kw servomotor 2kw servomotor 2kw servomotor 2kw servomotor2kw servomotor 2kw servomotor2kw servomotor 2kw servomotor 2kw servomotor 2kw servomotor 2kw servomotor 2kw servomotor2kw servomotor2kw servomotor2kw servomotor2kw servomotor2kw servomotor
|
||||||||||||
Model |
110-02030 |
110-04020 |
110-04030 |
110-05030 |
110-06020 |
110-06030 |
||||||
Rated Power（kW） |
0.6 |
0.8 |
1.2 |
1.5 |
1.2 |
1.8 |
||||||
Rated Current（A） |
2.5 |
3.5 |
5.0 |
6.0 |
4.5 |
6.0 |
||||||
Rated Torque（N·m） |
2 |
4 |
4 |
5 |
6 |
6 |
||||||
Max Torque（N·m） |
6 |
12 |
12 |
15 |
12 |
18 |
||||||
Rated Speed（r/min） |
3000 |
2000 |
3000 |
3000 |
2000 |
3000 |
||||||
Rotor Inertia（Kg·m2） |
0.31×10-3 |
0.54×10-3 |
0.54×10-3 |
0.63×10-3 |
0.76×10-3 |
0.76×10-3 |
||||||
Torque Coefficient (N.m/A) |
0.8 |
1.14 |
0.8 |
0.83 |
1.3 |
1.0 |
||||||
Counter EMF (V/1000r/min) |
56 |
79 |
54 |
62 |
83 |
60 |
||||||
Wire-wound (Ω) |
3.6 |
2.41 |
1.09 |
1.03 |
1.46 |
0.81 |
||||||
Wire-inductance (mh) |
8.32 |
7.3 |
3.3 |
3.43 |
4.7 |
2.59 |
||||||
Electrical Time Constant (Ms) |
2.3 |
3 |
3 |
3.33 |
3.2 |
3.2 |
||||||
Weight (Kg) |
4.5 |
6 |
6 |
6.8 |
7.9 |
7.9 |
||||||
Input Voltage Of Driver (V) |
AC220V |
|||||||||||
Number Of Encoder (P/R) |
2500/Absolute type 17bit |
|||||||||||
Pole-Pairs |
4 |
|||||||||||
Insulation Class |
F |
|||||||||||
Environment |
Temperature：-20℃～+40℃ Humidity：Relative≤90% |
|||||||||||
Protection Class |
IP65 |
|||||||||||
