High Torque NewKer 180mm 2000rpm AC 2KW Servo Motor Similar With Yaskawa Motor

High Torque NewKer 180mm 2000rpm AC 2KW Servo Motor Similar With Yaskawa Motor thumbnail-1
High Torque NewKer 180mm 2000rpm AC 2KW Servo Motor Similar With Yaskawa Motor thumbnail-2
High Torque NewKer 180mm 2000rpm AC 2KW Servo Motor Similar With Yaskawa Motor thumbnail-3
High Torque NewKer 180mm 2000rpm AC 2KW Servo Motor Similar With Yaskawa Motor thumbnail-4
High Torque NewKer 180mm 2000rpm AC 2KW Servo Motor Similar With Yaskawa Motor thumbnail-5
High Torque NewKer 180mm 2000rpm AC 2KW Servo Motor Similar With Yaskawa Motor photo-1
High Torque NewKer 180mm 2000rpm AC 2KW Servo Motor Similar With Yaskawa Motor photo-2
High Torque NewKer 180mm 2000rpm AC 2KW Servo Motor Similar With Yaskawa Motor photo-3
High Torque NewKer 180mm 2000rpm AC 2KW Servo Motor Similar With Yaskawa Motor photo-4
High Torque NewKer 180mm 2000rpm AC 2KW Servo Motor Similar With Yaskawa Motor photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Government ministry/Bureau/Commission
Year Established:
2007
Annual Export Value:
US$50 Million - US$100 Million
Contact Supplier Request Quote Chat Now
Chengdu Newker CNC-Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Poster
Products Description
PRODUCT:High torque NewKer 180mm 2000rpm AC Servo Motor similar yaskawa motor
180 Series of servo motor 2kw servomotor2kw servomotor2kw servomotor2kw servomotor2kw servomotor2kw servomotor2kw servomotor2kw servomotor2kw servomotor2kw servomotor2kw servomotor2kw servomotor
Model
180-17215
180-19015
180-21520
180-27015
180-35010
180-35015
180-48015
Rated Power（kW）
2.7
3.0
4.5
4.3
3.7
5.5
7.5
Rated Current（A）
10.5/6.5
12/7.5
16/9.5
16/10
16/10
24/12
32/20
Rated Torque（N·m）
17.2
19
21.5
27
35
35
48
Max Torque（N·m）
43
47
53
67
70
70
96
Rated Speed（r/min）
1500
1500
2000
1500
1000
1500
1500
Rotor Inertia（Kg·m2）
6.5×10-3
7.0×10-3
7.96×10-3
9.64×10-3
12.25×10-3
12.25×10-3
16.72×10-3
Torque Coefficient
(N.m/A)
1.7
1.58
1.34
1.69
2.2
1.45
1.5
Counter EMF
(V/1000r/min)
112/167
97/170
84/140
103/172
134/223
90/181
94/156
Wire-wound (Ω)
0.7
0.4
0.31
0.28
0.31
0.27
0.11
Wire-inductance (mh)
4.0
2.42
1.93
1.74
3.28
1.0
0.77
Electrical Time Constant
(Ms)
6.6
6.05
6.22
6.2
10.58
7.14
7
Weight (Kg)
19.5
20.5
22.3
25.5
30.5
30.5
40
Input Voltage Of Driver (V)
AC220V/380V
Number Of Encoder (P/R)
2500/Absolute type 17bit
Pole-Pairs
4
Insulation Class
F
Environment
Temperature：-20℃～+40℃ Humidity：Relative≤90%
Protection Class
IP65
Product applications
About us
Why Choose Us
Delivery procedures
FAQ
contact us
High torque NewKer 180mm 2000rpm AC 2KW Servo Motor similar with yaskawa motorHigh torque NewKer 180mm 2000rpm AC 2KW Servo Motor similar with yaskawa motorHigh torque NewKer 180mm 2000rpm AC 2KW Servo Motor similar with yaskawa motorHigh torque NewKer 180mm 2000rpm AC 2KW Servo Motor similar with yaskawa motorHigh torque NewKer 180mm 2000rpm AC 2KW Servo Motor similar with yaskawa motorHigh torque NewKer 180mm 2000rpm AC 2KW Servo Motor similar with yaskawa motorHigh torque NewKer 180mm 2000rpm AC 2KW Servo Motor similar with yaskawa motorHigh torque NewKer 180mm 2000rpm AC 2KW Servo Motor similar with yaskawa motorHigh torque NewKer 180mm 2000rpm AC 2KW Servo Motor similar with yaskawa motor
