NewKer -CNC DS503 series servo motor drive used in automation equipment

Name: NewKer -CNC DS503 series servo motor drive used in automation equipment
Price: Negotiable

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

Poster

Products Description

Product: NewKer -CNC DS503 series servo motor drive used in automation equipment

Single channel AC drive

Servo, absolute, modbus type

Dual channel AC drive

Servo, absolute, modbus type

380V AC drive

Servo, absolute, modbus type

Technical Parameters
Servo Driver	Output Current	Output Power	Output Torque	Channels	Power Supply
NK301i	30A	2.3KW	1~15NM	1 bus absolute	~220V
NK302i	2x30A	2x2.3KW	1~15NM	2 bus absolute
NK501i	50A	3.7KW	1~18NM	1 bus absolute
NK503i	50A	7.5KW	1~55NM	1 bus absolute	~380V
NK753i	75A	11KW	1~70NM	1 bus absolute	~380V
NK301iK	30A	2.3KW	1~15NM	1 bus absolute with full closed loop	~220V
NEW301	30A	2.3KW	1~15NM	1 absolute	~220V
NEW202	2x20A	2x1.2KW	0.1~6NM	2 absolute
NEW302	2x30A	2x2.3KW	1~15NM	2 absolute
NEW501	50A	3.7KW	1~18NM	1 absolute
NEW503	50A	7.5KW	1~55NM	1 absolute	~380V
NEW753	75A	11KW	1~70NM	1 absolute	~380V
DS301	30A	2.3KW	1~15NM	1 servo	~220V
DS202	2x20A	2x1.2KW	0.1~6NM	2 servo
DS302	2x30A	2x2.3KW	1~15NM	2 servo
DS301K	30A	2.3KW	1~15NM	1 servo with full closed loop
DS501	50A	3.7KW	1~18NM	1
DS503	50A	7.5KW	1~55NM	1	~380V
DS753	75A	11KW	1~70NM	1	~380V

Product features

The motor power adapt 100W-11KW

Single channel, two-channels AC servo motor driver controlling system

Switch to torque, speed, position, locate with point to point and mixed mode

Position control, speed control, servo electrical tool rest and JOG controlling mode

With bulit-in 4 segment locating postion could control point to point locate freely

Accuracy of locating ±0.01%

Input frequency of pulse is less than 500KHZ

Analog input: 0~10V or 0~±10V

Modified the space vector algorithm, the torque is bigger than the normal SPWM, the sound is lower

Overload capacity 300%

The power supply adapt ~220V±20% or ~380V±20%

Pefect protection: Overload current, overload voltage, overload heat, short circuit and fault of encoder

Many kinds of display:Rotating speed, current and offset position of motor, number of pulse, pulse frequency, straight line speed,
diagnosis of input and output, history records of alarm and so on

Product applications
