4/6/8-axis Robot Laser Cnc Hand Controller for Carving Lnc Injection Robot Controller
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Government ministry/Bureau/Commission
Year Established:
2007
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
7axis Robot Cnc Handheld Welding Controller and Touch Screen Cnc Robot Control Controller Remot Same as Fanuc Teach PendantNegotiableMOQ: 1 -
Industrial Robot Pendant Robot Control System 7 Axis Programmable 6axis Robot Cnc Welding Height ControllerNegotiableMOQ: 1
-
Touchscreen Robot Small Hand Cnc Torch Height Control Motion Controller for Robot Same as Scribit Robot ControlNegotiableMOQ: 1
-
8axis Robot Controller Industrial Robot Pendant Cnc Robot SystemNegotiableMOQ: 1
-
NEWKer-i6 Teach Pendant Robot CNC Controller for 6 Axis Industrial Steel Welding RobotNegotiableMOQ: 1
Poster
Products Description
Parameter details4 to 8 axis robot laser cnc hand controller for carving lnc injection robot controller4/6/8-axis robot laser cnc hand controller for carving lnc injection robot controller4/6/8-axis robot laser cnc hand controller for carving lnc injection robot controller4/6/8-axis robot laser cnc hand controller for carving lnc injection robot controller4/6/8-axis robot laser cnc hand controller for carving lnc injection robot controller4/6/8-axis robot laser cnc hand controller for carving lnc injection robot controller
No. of controller shaft | 4-8 axiscontrol panelof industrial automatic motoman arc welding robot(j1,j2,j3,j4,j5,j6) | Specify the welding current: | AA/S |
Type: | Bus absolute type and servo type | Specify the welding voltage: | VV/SS |
The most programminng: | ±99999.999 | Start welding: | AS* |
Encoder of motor: | 17bits and 23bits | End welding: | AE* |
I/O points: | 48*32 I/O | Start swing weld: | WS* |
0-10V analog: | 2 ways 0-10V analog | End swing weld: | WE |
Operation: | Teach,Repaly,Remote | Movement of joint: | MJ or MOVJ or GO |
Wifi function: | Connect with phone to send program | Movement od straight line: | ML or MOVL or G1 |
RS 232 function: | RS232 to connect with PC | Movement of arc: | MC or MOVC or G6 |
USB function: | Update and send program | Specify the speed: | V=to specify the feeding speed |
Program mode: | Teach,G code,Technics parameter | Specify the ratio: | VJ= to specify the feeding ratio |
Motion function: | Point to point,straight line,arc | The speed of changing track:(smoothness | PL= |
Instructions: | Movement,Logic,Calculation,Technics,G code in CNC | Start parallel translation: | SN* |
Coordinate system: | Joint,User,Tool,World | End parallel translation: | SF |
PLC function: | Edit the ladder,8000 steps | Read the current position: | PK*** |
Alarm information: | Emergency,drive,maintenance,error of starting arc and coordinate | Calculate the value of two position: | PX***=PT***-PT*** |
Limit function: | Soft limit | Start searching: | ST*P* |
Algorithm of controller: | 1)Vertical multi joint serial tobot; 2)Vertical articulated parallelogram robot; 3)Vertical multi joint L shape wrist robot; 4)Pole coordinate robot; 5)SCARA robot; 6)Delta robot; 7)Special robot; | End searching | SE |
Password protection: | Multilevel random password protection | Straight earching instruction: | SX+/-,SY+/-,SZ+/-, |
User macro program: | Have | The parallel value: | PX***=PX***+PX*** and PX***=PX***-PX*** |
Electrical gear function: | Have | G code: | The same as the standard cnc controller |
Application: | Welding,palletizing,Painting,Tending,Laser cutting and other special robor arm | Marco program instructions: | If..THEN;WHILE;GOTO;WAT |
Function 4 to 8 axis robot laser cnc hand controller for carving lnc injection robot controller4/6/8-axis robot laser cnc hand controller for carving lnc injection robot controller4/6/8-axis robot laser cnc hand controller for carving lnc injection robot controller4/6/8-axis robot laser cnc hand controller for carving lnc injection robot controller4/6/8-axis robot laser cnc hand controller for carving lnc injection robot controller
Product features
Never Crush the machine, the system with memorial function (Abosolute feature)
Needn't install hard limit in this 4-8 joint axis welding robot controller all kit and back to the zero point (Abosolute feature)
Use phone connect with controller by Wifi function, easier and more convenient to send program (NewKer feature)
G code program, only NewKer-CNC robot controller could work with G code program like cnc controller (NewKer feature)
Teach function with technics parameter, easier to operate (NewKer feature)
PLC and macro program are all opened (NewKer feature)
Only one cable come out from controller, easier to connect (Bus type feature)
Multilevel random password protection, more safety (NewKer feature)6-axis robot6-axis robot6-axi6-axis robots robot6-axis robot6-axis robot6-axis robot6-axis robot
Never Crush the machine, the system with memorial function (Abosolute feature)
Needn't install hard limit in this 4-8 joint axis welding robot controller all kit and back to the zero point (Abosolute feature)
Use phone connect with controller by Wifi function, easier and more convenient to send program (NewKer feature)
G code program, only NewKer-CNC robot controller could work with G code program like cnc controller (NewKer feature)
Teach function with technics parameter, easier to operate (NewKer feature)
PLC and macro program are all opened (NewKer feature)
Only one cable come out from controller, easier to connect (Bus type feature)
Multilevel random password protection, more safety (NewKer feature)6-axis robot6-axis robot6-axi6-axis robots robot6-axis robot6-axis robot6-axis robot6-axis robot
Product applications
