1.Product Name：New or Second-hand New Teach pendant Robot Spare Parts compatible with robot arm
2. Axis: 6 axis Teach pendant Robot Spare Parts
3. Application: Welding, pallatizing, painting, tending and other special
System function |
Program function |
||||
Number of control shaft： |
6 axis Teach pendant Robot Spare Parts （J1, J2, J3, J4, J5, J6, Xs, Ys） |
Specify the welding current: |
AA/S |
||
Type: |
Bus absolute type and servo type |
Specify the welding voltage: |
VV/SS |
||
The most programming： |
±99999.999 |
Start welding: |
AS* |
||
Encoder of motor: |
17 bits and 23 bits |
End welding: |
AE* |
||
I/O points: |
48X32 I/O |
Start swing weld: |
WS* |
||
0~10V analog: |
2 ways 0~10V analog |
End swing weld: |
WE |
||
Operation: |
Teach, Repaly, Remote |
Movement of joint: |
MJ or MOVJ or G0 |
||
Wifi function: |
Connect with Phone to send program |
Movement of straight line: |
ML or MOVL or G1 |
||
RS232 function: |
RS232 to connect with PC |
Movement of arc: |
MC or MOVC or G6 |
||
USB function: |
Update and send program |
Specify the speed: |
V= to specify the feeding speed |
||
Program mode: |
Teach, G code, Technics parameter |
Specify the ratio: |
VJ= to specify the feeding ratio |
||
Motion function: |
Point to point, straight line, arc |
The speed of changing track:(smoothness) |
PL= |
||
Instructions: |
Movement, Logic, Calculation, Technics, G code in CNC |
Strat parallel translation： |
SN* |
||
Coordiante system: |
Joint, User, Tool, World |
End parallel translation: |
SF |
||
PLC function: |
Edit the ladder, 8000 steps |
Read the current position: |
PK*** |
||
Alarm information: |
Emergency, drive, maintenance, error of starting arc and coordinate |
Calculate the value of two position: |
PX***=PT*** - PT*** |
||
Limit function： |
Soft limit |
||||
Algorithm of controller: |
1) Vertical multi joint serial robot; 2) Vertical articulated parallelogram robot; 3) Vertical multi joint L shape wrist robot; 4) Pole coordinate robot；
5) SCARA robot； 6) Delta robot； 7) Special robot； |
The parallel value: |
PX*** = PX*** + PX*** and PX*** = PX*** - PX*** |
||
Password protection： |
Multilevel random password protection |
G code: |
The same as the standard cnc controller |
||
User macro program： |
Have |
||||
Electrical gear function： |
Have |
||||
Application： |
Welding, Palletizing, Painting, Tending, Laser cutting and other special robot arm |
||||
Product features
★ Never Crush the machine, the system with memorial function (Abosolute feature)
★ Needn't install hard limit in this 4-8 joint axis welding robot controller all kit and back to the zero point (Abosolute feature)
★ Use phone connect with controller by Wifi function, easier and more convenient to send program (NewKer feature)
★ G code program, only NewKer-CNC robot controller could work with G code program like cnc controller (NewKer feature)
★ Teach function with technics parameter, easier to operate (NewKer feature)
★ PLC and macro program are all opened (NewKer feature)
★ Only one cable come out from controller, easier to connect (Bus type feature)
★ Multilevel random password protection, more safety (NewKer feature)
Our Seller
Name:JinHua Chen
Tel:13981709850
QQ:706983380
E-mail:706983380 @qq.com
Our Techinical Service
Name:GuangCan Liao
Tel:13550063039
QQ:357022449
E-mail:357022449 @qq.com
Our Customer Service
Name:Xin Liao
Tel:13548198210
QQ:461536982
E-mail:461536982 @qq.com
Factory
Warehouse
Our Warehouse(6-axis robot controller)
Test Room
24 hours work in different tempreture and humidity(6-axis robot controller)
Reception
Our Reception(6-axis robot controller)
1.Industrial packing(New or Second-hand New Teach pendant Robot Spare Parts compatible with robot arm): plastic bag +styrofoam+ carton +wooden pallets
2.Commercial packing: plastic bag+styrofoam+ carton
3.As the clients' requirement
Delivery Detail: Normally ready goods and stock within 1-3days
1. Special logistics packaging(6-axis robot controller)
2. Suitable carton size
3. Shock bubble film
4. Professional placement
5. Professional shock
6. Complete package
Our product after strict many test and examine
Our purpose:
Make the most practical ideal CNC system
Casting the high-quality goods to service the world
Our customer
Our customer is using our set of controller kit to control welding robot arm (NewKer-i6 4-8 joint axis welding robot controller all kit).
Our customer
Our customer is using our set of controller kit to control palletizing robot arm (NewKer-i6 4-8 joint axis welding robot controller all kit).
Our customer
Our customer is using our set of controller kit to control tending robot arm (NewKer-i6 4-8 joint axis welding robot controller all kit).
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: What is your terms of payment ?
A: 100% in advance.
