The Professional Supplier for Commercial Uht Tube in Tube Sterilizer for Tomato Catchup

Gofun Company has created the advanced automatic tube in tube sterilizer by learning and absorbing the high tech from Italy. The tube in tube sterilizer is widely used for the concentrated fruit paste and other products with high viscosity.

The Sterilizer has 4 layers tubular structures, the inner two layers and the outside layer will go through with the hot water and the middle layer will be running with the product. The product will be heated by the hot water to the setting temp and then hold the product under this temp for few time to completely sterilized the product and then cool down the product by the cooling water or chilled water. The sterilizer will be consist of the product tank, the pump, the heat exchanger, the holding tubes and the control system.

Put the product from a storage tank mounted for the sterrilizer into the heat exchanger unit.

Heat the product by superheated water till the sterilizing temp and hold the product under the temp fot sterilizing the product,then cool down into filling temperature by cooling water or chilled water.

Before each production shift, sterilize in place the system with aseptic filler together by superheated water.

After each production shift, clean in place the system with aseptic filler together by hot water, alkali liquid and acid liquid.
