Stable Automatic Swing Type Ceramic Granulator Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Government ministry/Bureau/Commission
Year Established:
2011
Annual Export Value:
US$1 Million - US$1.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
304 Stainless Steel Instant Swing Powder Granule Making MachineNegotiableMOQ: 1 -
Garlic Peeling Machine / Garlic PeelerNegotiableMOQ: 1
-
Stainless Steel Industrial Vacuum Tray Dryer Oven Fruit Food Drying MachineNegotiableMOQ: 1
-
6KW Commercial Fruit Fish Drying Machine Drying OvenNegotiableMOQ: 1
-
Hot Air Circulating Industrial Hair Dry Machine, Gelatin Drying Machine,tea Drying MachinesNegotiableMOQ: 1
Product Description
Product View
This machine is a kind of special equipment that compulsorily pass through the screen to make the wet powder mixture under the positive and negative rotation of the rotating drum. There are two types: normal type and heavy type. The heavy type uses materials with high viscosity and difficult to granulate. The agitated material is made into particles of the required size, or the agglomerated material is broken into small particles.
Performance characteristics:
Uniform granularity and simple control. The machine will make the wet powder mixture through the screen forcibly through the positive and negative rotation of the rotating drum to make granules. Adjusting the tightness of the screen and the rotation speed of the drum can control the particle size and density to a certain extent. The shaft rotation is well sealed and will not pollute materials: The main shaft of the machine is above the gearbox, and a tight shaft head sealing structure is designed to ensure that the shaft does not leak oil, do not wear materials, and prevent materials from being contaminated by lubricating oil, reaching GMP Claim.
Electromagnetic speed regulation has both deceleration and speed-increasing functions; the modified machine adopts electromagnetic speed regulation device to change the spindle speed, the faster the speed, the looser the particles; the slower the speed, the tighter the particles, and the particle size requirement can be achieved through the speed change. At the same time, the main shaft gearbox can speed up or slow down the main shaft according to the gear change.
Beautiful appearance, easy to clean; the machine shell is all packed with stainless steel wire drawing board, which is corrosion resistant. The parts cleaned by this machine are: the granulating cavity part. Mainly screens and hexagonal drums. The drum does not need to be disassembled, and the screen is easy to disassemble and cut lightly, and it is very convenient to clean.
Model |
Roller diameter (mm) |
Roller speed (r/min) |
Capacity (kg/h) |
Swing angle |
Power |
Weight |
Dimension |
OR-YK60 |
60 |
46 |
20-25 |
360 |
0.37 |
53 |
500*400*540 |
OR-YK100 |
100 |
55 |
30-100 |
360 |
1.5 |
180 |
700*400*1050 |
OR-YK160 |
160 |
55 |
150-300 |
360 |
3 |
280 |
1260*750*1150 |
OR-YK250 |
250 |
55 |
200-500 |
360 |
5.5 |
320 |
1260*900*1400 |
OR-YK320 |
320 |
55 |
300-800 |
360 |
7.5 |
500 |
1300*1100*1500 |
Product Display
Packing & Delivery
Packing: The normal package is wooden. If export to european countries,the wooden box will be fumigated.
FOB
Sea freight
Air freight
About us
Company Profile
Luohe Orange Mechanical Equipment Co.,Ltd (Orange) is a professional mechanical equipment manufacturer which is located in Henan Province, China. The company is specialized in production, processing and sales of food machinery, agriculture machinery and other machineries. The main production scopes that we cover are: snack food processing machines, candy processing machines, fruit and vegetables processing machines, packaging machines, water well drilling machines, and various peeling machines.
The company covers 35,000 m2and the fixed asset of the company is RMB 10 million Yuan. There are over 100 employees, more than 30 technicians, and over 100 sets of various manufacturing equipment. The equipment are included: large scale forcing press machine, digital lathe, digital wire-electrode cutting equipment, various kinds of processing machines and equipment, etc. The company owns national patents and proprietary technology with independent ....
Our Service
1. Inquiry and consulting support
2.Sending machine video for reference
3.Testing machine before delivery according to requirements.
4.View our Factory
After-sales service
Help training customer operation machine
Solve the customer's problem when machines in use through online video
The large equipment or complex machine , appointed engineer overseas service
