DZS310 No Display Compact 3 Phase Kwh Electronic Meter With CT

DZS310 No Display Compact 3 Phase Kwh Electronic Meter with CT

DZS310 is Din rail multifunction three phase energy meter. It is measuring active energy with accuracy CL.0.5. Set up for multi communication protocols as Modbus RTU, DL645.It can be used for reliable and trustworthy metering of energy usage and widely applied in smart buildings, retrofit projects.

Features & Functions

• 3* Single Phase or Three Phase Configured According to Your Site

• Measuring all parameters: three phase voltage, current, line voltage, active power, reactive power, apparent power, power factor, frequency, active energy, reactive energy

• CT, PT or voltage direct connected, suitable for various wiring modes under high or low pressure environment

• 1 interface* RS485

• Modbus RTU communication protocol

• 1* programmable energy pulse output
