Modbus AC 380V/100A DIN Rail Digital 3 Phase 4 Wire Smart Energy Meter KPM33A

Modbus AC 380V/100A DIN Rail Digital 3 Phase 4 Wire Smart Energy Meter KPM33A thumbnail-1
Modbus AC 380V/100A DIN Rail Digital 3 Phase 4 Wire Smart Energy Meter KPM33A thumbnail-2
Modbus AC 380V/100A DIN Rail Digital 3 Phase 4 Wire Smart Energy Meter KPM33A thumbnail-3
Modbus AC 380V/100A DIN Rail Digital 3 Phase 4 Wire Smart Energy Meter KPM33A thumbnail-4
Modbus AC 380V/100A DIN Rail Digital 3 Phase 4 Wire Smart Energy Meter KPM33A thumbnail-5
Modbus AC 380V/100A DIN Rail Digital 3 Phase 4 Wire Smart Energy Meter KPM33A photo-1
Modbus AC 380V/100A DIN Rail Digital 3 Phase 4 Wire Smart Energy Meter KPM33A photo-2
Modbus AC 380V/100A DIN Rail Digital 3 Phase 4 Wire Smart Energy Meter KPM33A photo-3
Modbus AC 380V/100A DIN Rail Digital 3 Phase 4 Wire Smart Energy Meter KPM33A photo-4
Modbus AC 380V/100A DIN Rail Digital 3 Phase 4 Wire Smart Energy Meter KPM33A photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Trading Company
Year Established:
1993
Annual Export Value:
US$2.5 Million - US$5 Million
Contact Supplier Request Quote Chat Now
Henan Compere Smart Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Product Overview

DIN RAIL 3 PHASE WIRELESS SMART ENERGY METER

KPM33 three-phase smart energy meter with DIN35mm type installation structure, LCD display, measurement of electrical energy and other electrical parameters, it can set some parameter, such as the clock, rate period, and so on, it also own electrical energy pulse output function; default RS485 communication interface, optional WIFI connection.

The energy meter has the advantages of small physical protection, high precision, good reliability and convenient installation, and the performance indexes are in line with the requirements of the national standard and power industry standard. The technical requirements for government agencies and large public buildings in the measurement of electrical energy can also be used for enterprises and institutions for energy management assessment.
FEATURES AT A GLANCE
Application
1. Intelligent distribution management system

2. Internal energy consumption statistical analysis and charging statistics basis

3. Energy metering, automatic meter reading system

4. Energy and energy efficiency management system
Feature
1. Measurement of three-phase voltage, current, active power, reactive power, apparent power, power factor, frequency,
active energy, reactive energy
2. Multi-rate energy statistics, a day can be set up to eight time periods, four kinds of rates historical power statistics function
3. Rated current 10-100A
4. LED indicates pulse, phase failure, reverse power, communication status
5. 1 road passive optical coupler collector active pulse output
6. 1 –way RS485 communication interface, default Modbus protocol, optional WIFI communication.
7. 7 +1 bit LCD display a variety of power parameters and information
8. Built-in clock and maintenance-free battery, real-time monitoring, data is permanently saved after power off
9. 35mm standard DIN rail installation, beautiful appearance, easy installation
10. Optional built-in relay for remote control
Details Images
Product Paramenters
KPM33Multifunction meter-Technical parameters
Input voltage
Rated voltage
AC 3x220V/380V
Overall power consumption
<2VA/
Frequency range
45~65Hz
Input current
Rated current
10-100A
Frequency range
45~65Hz
Measurement accuracy
Voltage
±0.2%(0.01V)
Current
±0.2%(0.01A)
Active power
±0.5%(0.1W)
Reactive power
±2.0%(0.1kvar)
Active energy
±0.5%(0.1kWh)
Reactive energy
±2.0%(0.1kvarh)
Power factor
±0.5%(0.001)
Frequency
±0.02Hz(0.01Hz)
Clock
Clock accuracy
<0.5S/D
Communication
Communication interface
RS485,Photoelectric isolation interface
Communication protocol
Modbus-RTU,1200~38400bps
Electrical insulation
Power frequency withstand voltage
AC2kV/min~1mA Input-output-power source
Insulation resistance
>50MΩ
Impact voltage
5kV(Peak),1.2/50us
Working environment
Operating temperature
-25℃ ~ +70℃
Relative humidity
5%~95% No condensation
Storage temperature
-30℃ ~ +75℃
Altitude
No more than 4000m
