3 Phase Digital Power Meter Multifunction With Modbus-RTU/DP Energy and Power Quality Analyzer Power Logger
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Trading Company
Year Established:
1993
Annual Export Value:
US$2.5 Million - US$5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Factory Wholesale 3-phase Power Meter With RS485 Port and Modbus-RTU Protocol Power Quality Analyzer MeterNegotiableMOQ: 1 -
Digital Energy Meter Power Analyzer Power Factor Meter LCD Power Quality MonitoringNegotiableMOQ: 1
-
Kpm75 Three Phase Energy and Power Quality Analyzer Power Factor Meter Digital Power Meter PriceNegotiableMOQ: 1
-
KPM75 Energy Analyzer Electrical Network Analyzer Power QualityNegotiableMOQ: 1
-
Three Phase Power Quality and Energy Analyzer Digital Power MeterNegotiableMOQ: 1
Product Overview
Smart three phase LCD display smart power meter/digtal display power meter with RS485
KPM53 series rs485 smart meter with accurate measurement of power parameters,the instrument uses advanced ARM processor and digital signal processing technology designed from the set of three-phase electrical parameters measurement,display, power statistics,power quality analysis,digital input/Output and network communications in one;with high precision,strong isolation,stable performance,anti-interference ability and a little; the instrument also has a very strong expansion capabilities,such as monitoring of external switching action,4-20mA analog output,but also The network management of the instrument can be realized through RS-485/Modbus communication protocol.
FEATURES AT A GLANCE
1.Alternative analog pointer table.
2.Display and control of electrical parameters in mid-low voltage distribution System.
3.Collect energy consumption data that cost center analysis needs.
4.Green building or DC.
Details Images
Product Paramenters
Technical Parameters | ||||||||
KPM 53 smart digital commercial electric meter | ||||||||
Accuracy Class | Voltage: 0.2; Current: 0.2; Frequency: 0.02 Hz; Power Factor: 0.5 | |||||||
Active Power: 0.5S; Reactive Power: 2.0 | ||||||||
Active Energy: 0.5S; Reactive Energy: 2.0 | ||||||||
Input | Rated Value | Voltage: 57.7/100V, 220/380V,380/660V Current: 1A(0~1.2A), 5A (0~6A) | ||||||
Overload | Voltage: Sustained Overload: 1.2 times of the rated value | |||||||
Momentary Overload: 2 times of the rated value, allows 1s | ||||||||
Current: Sustained Overload: 1.2 times of the rated value | ||||||||
Momentary Overload: 20 times of the rated value, allows 1s | ||||||||
Frequency | 45-60Hz | |||||||
Functional Module | Pulse Output | 1 | ||||||
Interface | 1*RS485; Modbus RTU protocol; Baud Rate: 1200-38400 bps | |||||||
Power Supply | Working Range | AC: 85-265V; DC: 80-300V | ||||||
Consumption | < 3VA | |||||||
Working Condition | Temperature | Operating: -25°C~+70°C. Storage: -30°C~ +75°C | ||||||
Humidity | 5%~95% No condensation | |||||||
Altitude | <4000m | |||||||
Dimensions: | 96×96×88mm | |||||||
