RS485 port/Modbus-RTU 220V single phase watt hour smart meter price
KPM51 single-phase intelligent power meter is a single-phase multi-function intelligent power meter integrating telemetry, remote signaling, remote control and transmission. It is rich in functions and cost-effective. It can be used independently for power measurement and display in different occasions, helping customers to save. Investment and use space has been widely used in various industries.
Technical Parameters:
|
KPM51 single phase watt hour analog electric meter |
||
|
Accuracy Class |
Voltage: 0.2; Current: 0.2; Frequency: 0.02 Hz; Power Factor: 0.5 |
|
|
Active Power: 0.5; Reactive Power: 2.0 |
||
|
Active Energy: 0.5; Reactive Energy: 2.0 |
||
|
Input |
Rated Value |
Voltage: 220V |
|
Frequency |
45-60Hz |
|
|
Functional Module |
Pulse Output |
1 |
|
Interface |
1*RS485; Modbus RTU protocol; Baud Rate: 1200-19200 bps |
|
|
Power Supply |
Working Range |
AC: 85-265V; DC: 80-300V |
|
Consumption |
< 3VA |
|
|
Working Condition |
Temperature |
Operating: -25°C~+70°C. Storage: -30°C~ +75°C |
|
Humidity |
5%~95% No condensation |
|
|
Altitude |
<4000m |
|
|
Dimensions: |
96×48×72mm |
|
|
|
|
|
If you are interested in it, please feel free to contact us and we will serve you sincerely!
