CU/CCS/CCA 50 Ohm Low Loss Lmr400 PE/PVC/LSZH Jacket Coaxial Cable
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
RF LMR-400 Coaxial Cable
-
CU/CCS/CCA 50 Ohm Low Loss LMR 600 PE/PVC/LSZH Jacket Coaxial Cable
-
Sell 50 Ohm Cable LMR 400-UF
-
CU/CCS/CCA 50 Ohm Low Loss Rg8 PE/PVC/LSZH Jacket Coaxial Cable
-
CU/CCS 50 Ohm Coaxial Cable Low Loss LMR400 PE/PVC/LSZH Jacket Coaxial Cable
-
CU/CCS/CCA 50Ohm Low Loss LMR400 PE/PVC/LSZH Jacket Coaxial Cable
Product Description
FLMR400
Construction
|
Item |
Material |
Diameter(mm) |
Remarks |
|
Inner Conductor Dielectric First Shield Second Shield Jacket |
Copper Clad Aluminum Foam PE Bonded Aluminum Foil TC Wire Braid PVC |
2.74 7.24 7.39 8.13 10.29 |
|
Electrical Characteristics
|
Impedance (Ω) Capacitance (pF/m) Velocity of Propagation (%) Return Loss Screening Effectiveness(db) Voltage With Stand Installation Temp(℃) Operating Temp(℃) Bending radius(mm) |
50±3 78.4 85.0 ≥18 ≥90 2000.0 -30 to +70 -30 to +70 Min. 200 |
Attenuation (@200C)
|
Frequency(MHz) |
Max Attenuation(dB/100m) |
|
150 450 900 1500 1800 2000 2500 |
5.0 8.9 12.8 16.8 18.6 19.6 22.2 |
