China Manufacturer LSZH Jacket Steel Wire/FRP/KFRP G652/G657/655 Indoor and Outdoor FTTH Drop Cable GJYXFCH

Fiber count

1/2/4/6/8/12

Color Of fiber

Blue Orange Green Brown

Fiber Type

G652D/G657A1/G657A2

Strength member

Steel wire/FRP/KFRP

Supporting messenger wire

1.0MM*x1 steel wire

Outer sheath

LSZH Lower smoke zero halogen frame retardant & UV Anti

Cable Diameter dimensions

2.0( Height) × 5.0W ± 0.1 mm(width)

Operation temperature range

-20 ℃ to + 70 ℃

Installation temperature range

-20 ℃ to + 60 ℃

Transport and storage temperature range

-20 ℃ to + 70 ℃

Tension Load (N)

Short term :800N  Long term :500N

Crush Load(N)

Long term 1000 N/100mm  Short term:2200N/100mm

Minimal installation bending radius

30 x OD

Minimal operation bending radius

15 x OD

Cable marking

The marking length 1meter apart , as required

1. Standard Packaging:

Rolled by wooden wooden drums. 2000m

to 6000m/drum or other required.

2. Sheath mark:

The following printing(white hot foil

 indentation)is applied at 1meter intervals.

a. Supplier: Guanglian or as customer required

b. Standard Code(Product Type, Fiber Type,

 Fiber Count)

c. Year of manufacture: 7 years

d. Length marking in meters.

1.We are the one of biggest manufacture of fiber optic

cable in China and has more than 10 years manufacturing

 and selling experience.

2.We accept OEM. The cable size and material are customized.

Ur own logo and own design are welcome.  We will produce

according to your requirment and description;

3.Please send us inquiry for more products info and we will

 give you feedback in 12 hours.
