Preferential Price Acsr Bison 266.8 Mcm Acsr Bare Conductor 100mm2 Acsr Linnet Kabel
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
1993
Annual Export Value:
Above US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
FDB Equipment Terminal Box 4core 12core 24core 48core Fiber Optic Distribution Box Fiber Splitter BoxNegotiableMOQ: 1 -
Hot Sale FDB Equipment Terminal Box 4core 12core 24core 48core Fiber Optic Distribution Box Fiber Splitter BoxNegotiableMOQ: 1
-
GL 8mm 9mm 10mm 11mm 250m 300m Fishtape Fiberglass FRP Traceable Wire Duct Rod Cable Snake Running Rod And Conduit Cable DuctNegotiableMOQ: 1
-
GL 192core 216core 288core Singlemode Air Blown Optical Fiber Micro Cable Blowing Into Underground Telecom Duct 18/14mm 20/16mmNegotiableMOQ: 1
-
China Manufacturer Fast Delivery 24 Core Fiber Optic Cable GCYFTY Air Blown 24 Core Micro Fiber Optic CableNegotiableMOQ: 1
Products Description
Application Features
Use in aerial bundled conductor (ABC) systems for city power grid transmission line.
Operating voltage up to 600/1000 volts.
Main for overhead single-phase and three-phase electricity distribution and other purposes.Stable working temperature -10°C to 80°C
Economical - Good electricity property and cheaper than cooper cables.Flexible - easy to install and work with distributions and other applications.Safe - prevent electric short circuit and potential risk of fire.Durable - anti UV Radiation and moisture, Corrosion Resistance.Aesthetically pleasing - Good finishing is guaranteed.Adaptable - physical properties and electricity suits Africa environment and market.
Specifications
Conductor Technical Structure | Unit | Value | ||||
Structure | Center: steel wire | Nos./mm | 1/2.0 | |||
Layer 1:steel wire | 6/2.0 | |||||
Layer 2: Aluminum wire | 10/2.57 | |||||
Layer 3: Aluminum wire | 16/2.57 | |||||
Standard | / | GB/T1179/IEC 61089/ASTM B232 / B232M-2009 / B498 | ||||
Stranding direction of outer layer | Direction | Right-hand | ||||
Conductor diameter | mm | 16.28±1％ | ||||
Cross section | mm2 | 156.8±1％ | ||||
Conductor weight | kg/km | 547.8±1％ | ||||
Rated tensile strength | kN | 52 | ||||
Modulus of Elasticity | GPa | 73.9 | ||||
Coefficient of linear expansion | 10-6/℃ | 18.9 | ||||
Max. DC Resistance at 20℃ | Ohm/ft | 0.637 | ||||
Lay ratio | Aluminum layer | times | 16-wire layer 10-14 10-wire layer 10-16 | |||
Steel layer | 6-wire layer 18-30 | |||||
Properties of Aluminum Wire (Before Stranding) | Unit | Value |
Diameter and tolerance | mm | 2.57±0.03 |
Min. tensile strength | MPa | 175 |
Min. elongation at 250mm | % | 1.7 |
Max. resistivity at 20℃ | Ω·mm2/m | 0.028172 |
Properties of Steel wire (Before stranding) | Unit | Value |
Diameter and tolerance | mm | 2.0±0.02 |
Min. tensile strength | MPa | 1410 |
Min. tension at 1% elongation | MPa | 1280 |
Min elongation at 250 mm | % | 3.5 |
Class of zinc coating | / | Class A |
Zinc coating quality | g /mm² | 230 |
Conductor diameter | MM | 6.0 |
Rated tensile strength | KN | / |
packaging
Packaging & Shipping
Packing : Steel wooden drum (fumigation) Cable length in each drum: 1000m/2000m or as per actual cable length
requirements. Drum size: As per cable length and container size *In order to quote you accurate price, kindly tell us your needed
cable length quantity. Larger quantity, more discount benefit ready for you! Shipping Port:Tianjin, Qingdao, or other ports as per
your requireents. Sea freight:FOB/C&F/CIF quotation are all available. *For some countries such as Africa countries, middle east
countries, our sea freight quotation is much cheaper than clients get from local shipping agency.
requirements. Drum size: As per cable length and container size *In order to quote you accurate price, kindly tell us your needed
cable length quantity. Larger quantity, more discount benefit ready for you! Shipping Port:Tianjin, Qingdao, or other ports as per
your requireents. Sea freight:FOB/C&F/CIF quotation are all available. *For some countries such as Africa countries, middle east
countries, our sea freight quotation is much cheaper than clients get from local shipping agency.
Company Profile
Hunan Guanglian Optoelectronics Technology Co., Ltd. was established in 2009. The company is located in China Changsha, Hunan. The company is an AAA credit enterprise and a national high-tech enterprise. The company has passed ISO9001 quality certification, TLC product certification, management system certification, power cable access license, Coal safety certification, and has obtained a number of technical patents, and has a comprehensive and unique solution in the national grid optical fiber transmission project. If you need visit our factory , we will meet you at the airport or train station.
lso we can offer other service. Custom Merchandise:we can make cable as your need include the color ,size and so on.we also offer OEM .Complete Course Tracking:we can offer you the service from the business begin to you get the cable and use it
Cable sample : we can offer the sample free
