22 AWG 4-Conductor Stranded Control Signal Cable
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Wholesale Price Low Noise Adapter Bulk Microphone Cable
-
Top Quality Microphone Wire Mic Cable Microphone Cable
-
Best Price Good Quality Flat UTP/FTP Cat5e Cat6 Cat7 Rj45 Patch Cord Cable
-
Best Price Good Quality Flat UTP/FTP Cat5e Cat6 Cat7 Rj45 Patch Cord Cable
-
Gold Plated Sftp Cat7 Ethernet Cable Patch Cord Flat Rj45 3m 25ft 100ft Cat 7 Plug Network Cable
-
Rj45 Cat5e 24awg Utp Copper/cca/ccs Cable Connector Patch Cord Cable
Product Description
22 AWG 4-Conductor Stranded control signal cable
1. Overview
- Feature different strand lay-length, keeping good NEXT and FEXT, anti-electromagnetic disturbimprovement .
- Structure bare copper, PE insulation, FR PVC/LSOH PVC jacket, twinning structure, flexible added, easily cabling.
- Telephone cable trunk transmission .
2. Product Structure
| Model NO. | 4 core data cable |
| Conductor Dimension | 0.22mm² |
| Conductor Material | OFC/CCC/CCA |
| Insulation | 1. Water blocking swellable tape (optional) |
| 2. HD-PE (High density polyethylene) | |
| 3. 1.0mmHD-PE(Highdensity polyethylene) | |
Number Of Cores | 2core/4core/6core/8core/10core |
| Shielding | UTP/Polyester Tape/Al Foil |
| Ripcord yes/no | Yes with Nylon |
| Jacket | PVC (Polyvinyl-Chloride)/ LSZH (Low Smoke Zero Halogen)/PE |
| Separator | Mylar Spirally Wrapped |
| Color | Different color is available |
| Operating temperature | -20 ° C - +75 ° C |
| Service Life | 20~25 years |
3. Electrical Characteristic
| Frequency (MHz) | IL-Max (dB/100m) | NEXT Min(dB/100m) | PSNEXT Min(dB/100m) | ELFEXT Min(dB/100m) | RL-Min (dB) |
| 1 | 2.6 | 41 | 41 | 39 | 12 |
| 4 | 5.6 | 32 | 32 | 27 | 12 |
| 10 | 9.7 | 26 | 26 | 19 | 12 |
| 16 | 13.1 | 23 | 23 | 15 | 10 |
