Product description：
Item No. |
M3B |
M3C |
M3D |
M3R |
M3L |
M3Y |
M3PM |
M3PP |
M3PF |
M3PL |
M3HS |
Fluid |
Air |
||||||||||
Operation type |
External control |
||||||||||
Pressure range |
0-1.0 Mpa |
||||||||||
Proof pressure |
1.5Mpa |
||||||||||
temperature |
-20 to 70℃ |
||||||||||
Valve type |
3 port 2 position |
||||||||||
Port size |
05:M5 06:G1/8” 08:G1/4” |
||||||||||
Orifize size |
05:2.5mm2 110 :06:8.0mm2 210 : 06:9.0mm2, 08:12.0mm2 |
||||||||||
Lubrication |
Not required |
||||||||||
Feature
Exhaust outlet locates over the body, which is convenient to install muffler to decrease noise and pollution.
The external force required by direction-change of series of M5B, M5R and M5L is provided by external mechanism, which can be position test or [stroke switch] limit switch
M5C, M5D, M5Y, M5PF, M5PM, M5PP, M5PL and M5HS are operated manually, owning control joints with several structure forms and suitable for application under different conditions.
It is in sliding column structure that control force is not influenced by working pressure (that is, there is no back pressure effect); internal circle is sealed with good tightness and the direction-change is sensitive.
Lubricant is not necessary.
Multi-mounting makes it convenient to install and apply.
The control joints of series of M5C, M5D, M5Y, M5R and M5L are made of metal which has longer service life and more reliable and steady performance.
Company information：
Yister Electric Co., Ltd. specialized in manufacturing pneumatic products. The company adopts international advanced production technology and scientific management methods, and all products realize computer-aided design and production management. The key components are imported from Europe and the United States. The main performance indicators of the products have reached the international advanced level.
The products produced by our company are of high quality, reliable performance, good versatility, wide variety and complete specifications. The main products are multiple series of pneumatic actuators, control components, auxiliary components, pneumatic machinery and pneumatic complete systems.
FAQ
1.Q: what is your products?
A:Yister Pneumatic produce Pneumatic solenoid valve, Mechanical valve, foot valve, Air control valve, hand valve, cylinder, PU Tube ,pneumatic fittings,etc.
2.Q: how can we guarantee quality?
A:Warrenty is one-year. 100% Inspection before shipment;
3.Q:VF3130 VF3230 VF3330 solenoid valve is SMC original brand ?
A:No,ours VF3130 3 way solenoid valve is SMC replacement with same function
4.Q: why should you buy from us not from other suppliers?
A:We are the source manufacturer, and no dealers earn the price difference. All products have passed the strict pressure test and passed the packaging and delivery.
5.Q: what services can we provide?
A: After full payment, we place an order for production and deliver the goods within the agreed delivery time
Accepted Payment Currency:dollar
Accepted Payment Type: T/T
Language Spoken:English
6.Q.Whats your packing
A:Transparent plastic bag + white small box + neutral carton + pallet
