Yokogawa AAI143-S00 Analog Input Module With Best Price In Stock
Yokogawa AAI143 Analog Input Module is a 16 channels isolated Analog Input Module for 4 to 20mA Current Input signals.
Brand: Yokogawa
Place of origin: Singapore or Indonesia
AAI143 Analog Input Modules is a 16 channels isolated Analog Input Module can be installed on Field Control Unit or ESB bus node unit for 4 to 20mA Current Input signals from field instrument.
2. Standard Specification
Main Characters |
Description |
Number of input channels |
16, isolated |
Input signal |
4 to 20 mA |
Allowable input current |
24 mA |
Withstanding voltage |
Between input and system: 1500 V AC, for 1 minute |
Data update period |
10 ms |
Transmitter power supply |
19.0 V or higher (at 20 mA) 25.5 V or less (at 0 mA) (output current limit: 25 mA) |
Setting of 2-wire or 4-wire transmitter |
For each channel by setting pin |
Drift due to ambient temperature change |
±16 μA per 10 ˚C |
Maximum current consumption |
230 mA (5 V DC), 540 mA (24 V DC) |
External connection |
Pressure clamp terminal, MIL connector cable, dedicated cable (KS1) |
HART communication |
Available |
3. Model Selection of AAI143 Analog Input Module
Model |
Suffix Codes |
Description |
|||
AAI143 |
Analog Input Module (4 to 20 mA, 16-channel, Isolated) |
||||
-S |
Standard type |
||||
-H |
With digital communication (HART protocol) |
||||
5 |
Standard type with no explosion protection |
||||
E |
Standard type with explosion protection |
||||
0 |
Basic type |
||||
3 |
With ISA Standard G3 option and temperature (-20 to 70 °C) option |
||||
Option Code |
/K4A00 |
With KS Cable Interface Adapter (For connecting AEA4D Terminal Board) [Model: ATK4A-00] |
|||
/A4S00 |
With Pressure Clamp Terminal Block [Model: ATA4S-00] |
||||
/A4S10 |
With Pressure Clamp Terminal Block (surge absorber) [Model: ATA4S-10] |
||||
/A4D00 |
With Dual Pressure Clamp Terminal Block [Model: ATA4D-00] |
||||
/A4D10 |
With Dual Pressure Clamp Terminal Block (surge absorber) [Model: ATA4D-10] |
||||
/CCC01 |
With Connector Cover for MIL Cable [Model: ACCC01] |
||||
4. Typical Order Codes
Typical order codes |
Remarks |
AAI143-S50 |
Standard type |
AAI143-S53 |
Standard type with ISA G3 and wide temperature (-20 to 70 °C) |
AAI143-H50 |
Hart type |
AAI143-H53 |
Hart type with ISA G3 and wide temperature (-20 to 70 °C) |
AAI143-S50/K4A00 |
Standard type with ATK4A terminal block |
AAI143-S53/K4A00 |
Standard type with ISA G3 and wide temperature (-20 to 70 °C) with terminal block |
AAI143-H50/K4A00 |
Hart type with ATK4A terminal block |
AAI143-H53/K4A00 |
Hart type with ISA G3 and wied temperature (-20 to 70 °C) with terminal block |
5.Dual-redundant System Configuration
6. External Dimension
