Wide use horizontal thin material sheeting machine
| Specifications | ||
|
Model |
HX-600B |
HX-1000B |
|
Voltage |
380V |
380V |
|
Total Power |
1.5KW |
1.5KW |
|
N.W. |
320KG |
510kg |
|
Cutting Length |
0.1-9999.9mm |
0.1-9999.9mm |
|
Cutting Width |
1-600mm |
1-1000mm |
|
Cutting precision |
±0.05mm |
±0.05mm |
|
(0-180mm)/Cuttingspeed |
125cuts/min |
100cuts/min |
|
Machine size |
1500x1300x1200mm |
1500*1800*1150mm |
The details of factory supply horizontal thin material sheeting machine
This machine emplys servo motor to feed material, import PLC touch screen operation to set any length, quantity, speed and finish singleness cutting, equipped with automatic wuwinding system and air shaft, which will be easy to load and unload.
1. Max material width: 600mm;
2. Tolerance: 0.05mm, Precision:±0.05mm;
3. Material thickness range: 0.5mm-15mm;
4. Cutting speed:125 cut/min;
5. Both kiss-cut and complete cut are available;
6. Complete cut is for standard machine, and kiss-cut is an option;
7. A conbination of PLC and servo motor.
8. An air shaft as the loading shaft;
9. Two accessories, static eliminator and conveyor belt, for you to choose
10. Automatic unwinding function;
11. Cutting length is accurate;
12. Operation is easy;
13. Waste rate is low;
14. Diverse functions satisfy your various requirements;
15. We offer superior-quality products and best service for you;
16. As a high-tech manufacturer, we possess veteran engineers and professional sales team;
17. Manufacturing experience: 10 years;
18. Export experience: 5 years.
Our machine can cut more than the samples showed .
Why we choose your machine .
1.the promptly reply within 24 hours .
2:Warranty for machines is three years and 36 months ( except the consumable parts ) .
3.wherever you are ,our professional engineers will flight to you to solve the problem
4."Quality is priority. HEXIN always attach great importance to quality controlling from the very beginning to the very end. Our factory has gained CE & ISO Certification .We have been procesing and manufacturing spare parts for APPLE and TOYOTA .
.More than 40 countries are using our shetting machine .
The other machine of our factroy
Customers visiting our Factory
CE Certification for PET,film sheeting machine with automatic unwinding system
Our machines meet CE requirement . Conform to the safety, health, environmental protection and consumer protection, and a series of European directives to express requirements . .
Letter of Patent
Utility Model Patent Certificate .Thirty years of production experience ,we spent a great deal of time to research new products ,won a number of utility model patent certificates .Some of our product are world first .
Our machines are widely applied in laminating, slitting and die cutting for protective materials, sticky materials, insulating materials, conductive materials, electronic materials, printing materials and so on, and sizing cutting for strings, strips, sheets, ropes, lines, belts, rolls, plates ,tubes, fibre, rubber, foam, Mylar, LCD, films, tapes, PET, PVC, PC, metal foils, etc. Our machines can process all kinds of sheet materials, roll materials and so on.
we will provide all our customers with reliable products, perfect service in order to create a brilliant future together.
Any help , please feel free to contact us.
