Help CenterAutomatic Two Unwind Roll Sticker Sheet Cutting Machine With Kiss Cut
Related Products
-
High Precision Automatic Foam And Tape Gap( Roll To Roll) Cutting MachineNegotiableMOQ: 1 -
800mm Width Super Cut Gap Cutter Kiss Cutting MachineNegotiableMOQ: 1
-
Max 600mm Width Long Strip Adhesive Tape Gap Cutting MachineNegotiableMOQ: 1
-
HX-600JXS 600mm Gap Kiss Cutting Machine for Conductive Fabric Reflective Film Double Side TapeNegotiableMOQ: 1
-
HX-600JXS 600mm Gap Kiss Cutting Machine for Conductive FabricNegotiableMOQ: 1
specifications:
|
Model |
HX-1600JXS |
|
Max.unwinding dia. |
350mm |
|
Max.rewinding dia. |
350mm |
|
Max.web width |
1600mm |
|
Max.cutting times |
180/min |
|
Cutting peecision |
±0.1mm |
|
Voltage |
380V 50Hz |
|
Air supply |
0.4-0.7MPa |
|
Main power |
2.2kw |
|
Total power |
6kw |
|
Machine size |
2350*1750*1500mm |
|
Machine weight |
3800kg |
Features:
©Taiwan Brand Servo motor & Japan brand PLC applied
©Touch screen with the ability to save parameters
©Cutting length and cutting speed adjustable
©Both Kiss-cut and full-cut are available, 6 different cutting models are available for your choice.
©Save raw materials for no waste discharging
©Unwinding roll material diameter can be customized
Application:
Our machine is suitable for jump cutting for conductive fabric, foam, diffusion film, double-sided tape,etc.
About Us
We are a team of industry professionals with strong backgrounds in cutting, die cutting, slitting, laminating
and rolling. Other related machines in our fields can be customized based on your specific requirements.
Kunshan Hexin Precise Machinery is located in Kunshan city,Jiangsu province. We are near
Shanghai,40 minutes away from Shanghai Hongqiao airport by car and 18 minutes by high speed train.
Established in 2007, we have been dedicated on converting machines which are used before and after
printing for over 10 years.
Our belief is “people-oriented, technology-first, integrity-centered and brand idea” to provide customers
reliable products, perfect service.Our products are widely applied in laminating, slitting and die cutting
for shield materials, sticky materials, insulating materials, conductive materials, electronic materials.
Sizing cutting for strings, belts, rolls in bag line, shoe and cap line and plastic and rubber line.
