1-160mm Automatic Roll Flat Cable Cutting Machine
This cutting machine can cut hook and loop fastener, fabric belt, elastic belt, plastic belt,
sleeve, paper, flat cable, small wire, etc. It adopts a servo motor and PLC control system to
achieve accurate cutting.
This cutting machine can cut more than following materials:
If you are not sure if your material can be cut by this machine, plz consult us and provide following information:
| Material: | |
| Max. material width: | |
| Max. material thickness: | |
| Max.cutting length(after cutting) |
Parameters:
|
Model |
HX-160 |
|
Voltage |
220V |
|
Power |
375w |
|
N.W. |
83kg |
|
G.W. |
133kg |
|
Cutting Length |
0.1~9999.9mm |
|
Cutting Width |
1~160mm |
|
Measurement |
550x550x1000mm |
Machine Features:
1. Tolerance: 0.05mm, Precision: 0.1mm;
2. Material thickness range: 0.5mm-15mm;
3. Cutting speed: about100-120 cuts/min;
4. This cutting machine has cold and hot model, by changing knife;
5. This cutting machine employs a microcomputer controller to set cutting length, speed, and quantity, and it will memorize them when it runs next time.
6. This cutting machine adopts a servo motor to make sure accuracy;
7. This cutting machine allows cutting several strips at the same time;
8. Operation is easy with a touch screen;
9. A material holder will be sent with this machine.
Details of this cutting machine :
Configuration List:
| Part Name | Place of Origin | Usage Qty |
| Touch screen | made in China | 1 |
| PLC | made in China | 1 |
| Power switch | made in Taiwan | 1 |
| Solid-state relay | made in Taiwan | 1 |
| Servo driver | made in Taiwan | 1 |
| Microswitch | made in Japan | 1 |
| Proximity switch | made in China | 1 |
| Cooling fan | made in China | 1 |
| Servo motor | made in Taiwan | 1 |
| Cutting knife motor | made in Taiwan | 1 |
| Reduction gearbox | made in Taiwan | 1 |
Options:
1. Hot cutting knife
2. Kiss cut (half cut) knife
3. Photoelectric eyes(for printing material)
4. Pneumatic system(for thick material)
5. Automatic unwinding/rewinding machine
1. We are a factory, and the price is favorable.
2. We have strict QC system.
3. We offer a free after-sales service for one year.
4. Our engineers are available to service machinery overseas.
5. Our machines have been sold to over 40 countries.
International certification:
Kunshan Hexin Precision Company is a collection of produciton,research and development, sales and service as one fo professional electronic machinery manufacturing enterprises. We specialized in microcomputer slicing machines, cutting machines, slitting machines, laminating machines and die-cuting machines for many years. Our company have obtained 11 paternts patents and passed the SGS factory qualification ceritficaiton adn the European Union CE certification. In 2013, we have got "national high-tech enterprise/" Our products are exported to Europe, America, Southeast Asia, the Middle East, Singapore, India,Thailand agents at abroad, our products enjoy a good reputaiton at domestic and international market.
1. We are a factory, and the price is favorable.
2. We have strict QC system.
3. We offer a free after-sales service for one year.
4. Our engineers are available to service machinery overseas.
5. Our machines have been sold to over 40 countries.
