1600mm Conductive Fabric Foam Diffusion Film Jump Cutting Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Other
Year Established:
1991
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
1600mm Conductive Fabric Foam Diffusion Film Jump Cutting MachineNegotiableMOQ: 1 -
Factory Automation Film Mini Slitting MachineNegotiableMOQ: 1
-
Small Automatic Roll to Roll Lamination MachineNegotiableMOQ: 1
-
Factory Automatic Adhesive Tape Log Roll Cutting Machine BOPP Tape Roll Cutting MachineNegotiableMOQ: 1
-
Made in China Factory Cutting Paper Plate MachineNegotiableMOQ: 1
Product Overview
Features:
Double servo, four sets of roller synchronous pull, to ensure the formation of gaps between product materials, up to 80% of raw materials!
The whole shaft, full magnetic powder control, and the tension adjustment is convenient;
Can be rack 1600 * 100mm knife mold, automatic pinch, no waste, environmental protection!
Uses: Suitable for the shaped, narrow strips of materials such as foam, diffusion sheet, double-sided tape, copper or aluminum foil, saving time and saving, high production efficiency increases!
Products Description
The jump knife cutting machine is to cut the whole roll or the whole raw material to a fixed length. Its blade is very sharp. The edge of the material after being cut by the jump knife cutting machine is smooth and flat without burrs. You can adjust the cutting speed and length of the jump knife cutting machine according to your needs. The system of jump knife cutting machine can adjust the parameters according to your needs. The tension controlled by the intermittent cutting machine is one of the guarantees for high cutting accuracy. It uses magnetic powder to control the tension, making it easier and more accurate to adjust the tension. For different materials and different thicknesses, it can adjust the tension separately. The jump knife cutting machine can cut a lot of materials, such as double-sided tape, copper foil, aluminum foil, and flannel, all of which can complete the cutting task easily and with high quality.
The jump knife cutting machine uses double servos and four sets of rollers to pull the material, so that a gap will be formed between the materials, which can save raw materials and avoid waste. The jump knife cutting machine can save up to 80% of raw materials, which is an amazing data. The jump knife cutting machine can realize automatic knife clamping, no waste discharge, very energy saving and environmental protection. Now environmental protection is also one of the concerns of people. The jump knife cutting machine is not only a machine that can maintain efficient cutting, but also an energy-saving machine. The kiss cutting machine with gap adopts high-precision frequency conversion speed regulation and circular-arc synchronous belt transmission, and the winding precision and stability have been improved to ensure the quality of the product.
With the development of technology, the machines are now more and more developed. No need to worry that you will not operate advanced machines. The operation of jump knife cutting machine is very simple and effective. It adopts PLC control system. I believe you will be able to learn to operate it easily.
The kiss cutting machine with gap is operated by the PLC touch screen. The set parameters will be displayed on the display screen, and you can adjust them according to your needs, such as the length, quantity, and speed of cutting materials. The jump knife cutting machine can meet any of your cutting needs. The gap cutting machine adopts PLC centralized control, which can execute instructions quickly and work efficiently.
The kiss cutting machine with gap is operated by the PLC touch screen. The set parameters will be displayed on the display screen, and you can adjust them according to your needs, such as the length, quantity, and speed of cutting materials. The jump knife cutting machine can meet any of your cutting needs. The gap cutting machine adopts PLC centralized control, which can execute instructions quickly and work efficiently.
The jump knife cutting machine can easily and efficiently cut large rolls of thin materials into the width of material you need.Not only can it process thin materials, but it can also help you check product quality. You can check the quality of the product through the sliced slices. It is worth mentioning that the jump knife cutting machine is not only suitable for cutting one material. The kiss cutting machine with gap can cut many materials, such as non-woven fabrics, tapes, lithium battery membranes and many other products. The jump knife cutting machine is extremely cost-effective, making it popular in the market. The material cut by the jump knife cutting machine has smooth edges, no burrs, and the cutting speed is very fast. A considerable amount of thin materials can be completed in a short time.
The gap cutting machine consists of an unwinding mechanism, a cutting mechanism, a winding mechanism, various functional rollers, a tension control system, a correction control system and a detection device. The film material passes through the flattening roller, the tension detection roller, the auxiliary energy roller, and the correction system, and then enters the cutting mechanism for cutting. Finally, the finished raw material is separately wound by the winding mechanism into the film rolls you need.
HEXIN's jump knife cutting machine adopts double-servo pull material. This design can ensure the formation of gaps between the product materials, which can save 80% of the raw materials under the most ideal conditions. HEXIN's jump knife cutting machine is controlled by full magnetic powder, which can more conveniently and accurately adjust the tension and ensure the quality of the product. The kiss cutting machine with gap is operated by PLC touch screen, which is easy to operate. You can set the length, quantity and speed of cutting materials according to your needs. HEXIN's jump knife cutting machine can provide individual cutting functions.
HEXIN's jump knife cutting machine adopts double-servo pull material. This design can ensure the formation of gaps between the product materials, which can save 80% of the raw materials under the most ideal conditions. HEXIN's jump knife cutting machine is controlled by full magnetic powder, which can more conveniently and accurately adjust the tension and ensure the quality of the product. The kiss cutting machine with gap is operated by PLC touch screen, which is easy to operate. You can set the length, quantity and speed of cutting materials according to your needs. HEXIN's jump knife cutting machine can provide individual cutting functions.
Knowing these precautions will make your jump knife cutting machine work better and work longer. Let's take a look together.
First of all, we recommend that you install the gap cutting machine in a place with proper temperature, dryness and ventilation. Humid environment may adversely affect the parts of the jump knife cutting machine. In addition, we also recommend that you install the jump knife cutting machine in a well-lit place, because the bright environment can facilitate your operation. Pay attention to keep the jump knife cutting machine clean and hygienic. jump knife cutting machine's consumable parts. For these parts, you need to check the wear and tear regularly. If the wear is serious, replace them in time.
· The above is all the content of this article, I hope this article can help you have a better understanding of jump knife cutting machine. We are an experienced manufacturer that can provide you with quality products, such as Hot Cutting Machine, Log Roll Cutting Machine. Welcome to contact us, we will be the choice you will not regret.
First of all, we recommend that you install the gap cutting machine in a place with proper temperature, dryness and ventilation. Humid environment may adversely affect the parts of the jump knife cutting machine. In addition, we also recommend that you install the jump knife cutting machine in a well-lit place, because the bright environment can facilitate your operation. Pay attention to keep the jump knife cutting machine clean and hygienic. jump knife cutting machine's consumable parts. For these parts, you need to check the wear and tear regularly. If the wear is serious, replace them in time.
· The above is all the content of this article, I hope this article can help you have a better understanding of jump knife cutting machine. We are an experienced manufacturer that can provide you with quality products, such as Hot Cutting Machine, Log Roll Cutting Machine. Welcome to contact us, we will be the choice you will not regret.
PRODUCT SPECIFICATIONS
Model |
HX-1600JXS |
Max.unwinding dia. |
350mm |
Max.rewinding dia. |
350mm |
Max.web width |
1600mm |
Max.cutting times |
180/min |
Cutting peecision |
±0.1mm |
Voltage |
380V 50Hz |
Air supply |
0.4-0.7MPa |
Main power |
2.2kw |
Total power |
6kw |
Machine size |
30000*2350*1530mm |
Machine weight |
4000kg |
PRODUCT CONFIGURATION
plc
knife
Sample
Our company
We are a team of industry professionals with strong backgrounds in cutting, die cutting, slitting, laminating
and rolling. Other related machines in our fields can be customized based on your specific requirements.
Kunshan Hexin Precise Machinery is located in Kunshan city,Jiangsu province. We are near
Shanghai,40 minutes away from Shanghai Hongqiao airport by car and 18 minutes by high speed train.
Established in 2007, we have been dedicated on converting machines which are used before and after
printing for over 10 years.
Our belief is “people-oriented, technology-first, integrity-centered and brand idea” to provide customers
reliable products, perfect service.Our products are widely applied in laminating, slitting and die cutting
for shield materials, sticky materials, insulating materials, conductive materials, electronic materials.
Sizing cutting for strings, belts, rolls in bag line, shoe and cap line and plastic and rubber line.
and rolling. Other related machines in our fields can be customized based on your specific requirements.
Kunshan Hexin Precise Machinery is located in Kunshan city,Jiangsu province. We are near
Shanghai,40 minutes away from Shanghai Hongqiao airport by car and 18 minutes by high speed train.
Established in 2007, we have been dedicated on converting machines which are used before and after
printing for over 10 years.
Our belief is “people-oriented, technology-first, integrity-centered and brand idea” to provide customers
reliable products, perfect service.Our products are widely applied in laminating, slitting and die cutting
for shield materials, sticky materials, insulating materials, conductive materials, electronic materials.
Sizing cutting for strings, belts, rolls in bag line, shoe and cap line and plastic and rubber line.
