automatic pneumatic sheet cutting machine (With PLC control)
Functions for automatic pneumatic sheet cutting machine :
This machine employs man-machine+ PLC system, with high speed air cylinder to make cutting efficiency multiply, This machine is ergonomically designed.Operation is easy.
Application for automatic pneumatic sheet cutting machine :
Sizing cutting for hook and loop fastener , cotton yarn belt, elastic band,plastic belt,zipper, sleeve,paper,flat cable,small wire,metal film,etc……
Main technical parameters for automatic pneumatic sheet cutting machine :
|
Model |
HX-160 C |
|
Voltage |
220V |
|
Power |
1/2HP |
|
N.W. |
80kg |
|
GW. |
130kg |
|
Cutting Length |
0.1-9999.9mm |
|
Cutting Width |
1-160mm |
|
Measurement |
550x550x1000mm |
Features for automatic pneumatic sheet cutting machine :
1. The max width: 160mm
2. Tolerence: 0.05mm, Precision: 0.1mm
3. Material thickness: 0.5mm-15mm
4. Kiss cut or cut through available
5. Under CE and ISO Certifications
6. Warranty for machine: 12months
7. Delivery time: 1-3days
Characteristics for automatic pneumatic sheet cutting machine :
1. This machine employs microcomputer controller to set belt cutting length.
2. The cutting length is accurate.
3. Operation is easy.
4. Waste rate is low.
5. Manufacturing experience: 30 years
6. Export experience: 20 years
7. Cut through for standard machine
Details pictures of automatic pneumatic sheet cutting machine
Our packing for automatic pneumatic sheet cutting machine is plywood case
After-sale service
1. Warranty for machines is 12 months
2. A promptly reply within 24 hours
3. Free usage training in factory before delivering machines
4.If our machines can't well meet your requirment ,we support customized machine .
Brief Introduction
Kunshan Hexin precise machinery co. Ltd is located in Kunshan city, Jiangsu province, it’s only 40 minutes' away from Shanghai Hongqiao airport by car,
and 18 minutes' away from Shanghai railway station by high-speed rail. The
traffic is very convenient.
We are specialized in developing, manufacturing, marketing and exporting
microcomputer belt cutting machines, slitting machines, laminating machines, high precision die cutting machines. With strong
technology, international quality control system and perfect after sale service, our products enjoy a good reputation both at home and aboard market.
with Japanese advanced design drawing and manufacturing technology,
our machines have come up to the leading levels after continuous improvement for many years, especially in mechanical and electrical, gas and liquid fields. We own professional technical staffs, engineers, sales and after-service
employees who constitute a young and well-qualified team. Our belief is
"people-oriented, technology-first, integrity-centered and brand idea" and we will provide all our customers with reliable products, perfect service in order to create a brilliant future together.
Our products are widely applied in laminating, slitting and die cutting for
protective materials, sticky materials, insulating materials, conductive materials, electronic materials, printing materials and so on, and SE for strings, strips, sheets, ropes, lines, belts, rolls, plates ,tubes, fibre , rubber,
PET, PVC, PC, metal foils, etc. Our machines can process all kinds of sheet materials, roll materials and so on.
Our factory
workshop for automatic pneumatic sheet cutting machine
The samples which use our machines to produce
Our products on Shanghai Expo
Customers Visiting our Factory
If you coming to visit our factory ,you will be warmly welcomed .
CE Certification
Our machines meet CE requirement . Conform to the safety, health, environmental protection and consumer protection, and a series of European directives to express requirements . For our products ,please rested assured .
Letter of Patent
Utility Model Patent Certificate .Thirty years of production experience ,we spent a great deal of time to research new products ,won a number of utility model patent certificates .Some of our product are world first .
1. Q: Are you a factory or trading company?
A: We are a factory and manufacturer
2. Q: Where is your factory located in ? How can I visit there?
A: Our factory is located in Kunshan which is very near from Shanghai, and
our detailed address is: Factory 9, No. 157, Wulian Road, Yushan Town,
Kunshan, Suzhou, Jiangsu, China. If you fly to Shanghai hongqiao airport
or Pudong airport, we can pick you up by car from there. We welcome all our clients, home and abroad, to visit us.
3. Q: what are your main products?
A: Our main products are belt cutting machines, slitting machines, sheeting
machines, laminating machines and rotary die cutting machines.
4.Q: Which industries can use your machines ?
A: All industries need to cut (include full cutting and kiss-cutting), slit,
laminate, rotary die cut raw materials can use our machines.
5.Q: How to control the quality in your factory ?
A: Quality is priority. We control the quality of our products strictly, from the
incoming materials to the finished products. Our factory has obtained
CE & ISO Certification
6. Q:If there are no machines available from your list, could we customize
non-standard machines from you ?
A: Yes, we have our own professional design engineers, and can customize
products according to your requirement.
