Home > Products > Cardboard stitching machinne/stitcher > Semi-auto Corrugated Carton Stitching Machine
Semi-auto Corrugated Carton Stitching Machine
- 1000 per Month
- T/T Credit Card
- Semi auto stitcher carton machine Corrugated cardboard stapling machine
- manul stapling/stitching machine fpr carton box
- Price of semi-auto stapling machine for corrugated carton box stiching machine good price
- carton stapling machine/carton box stapler
- manul carton Box Bottom Stapler
- Carton box pe belt strapping machine semi auto strapping machine
Product Description
Imported Japan 4 servo driving,high precise,with few mechanical driving part to reduce machine damage.
The whole control system adopt Omron PLC control system
The contactor in the control box adopt Siemens brand
Display and circuit breaker adopt schneider ,photo-electric switch and proximity switch adopt Omron branch
Bottom mould and blade adopt Japan Tungsten steel The whole stitching head adopt special steel to make,computer digital processed.
Change the size only need one minute to finish,same as changing the stitching distance
Can stitch box with lid or box no lid(when customer need the stitching the no lid box ,he must special order)
With automatic counting function in the back part,the finished carton can be delivery to the end by pile,(as the setting number 1--99),it is convenient to strap
Two function in one machine,can stitch single ,double carton,not normal carton
Size adopt whole electric type to control,changing size only need 2--3minute
Can stitch strengthen wire,single staple,double line stitch,finish on one time
Feeding part can automatic count
Suitable for medium and small type carton ,stitch quick and easy.
the computer set and automatic adjust the distance of stitching ,the stitch distance is 20--120mm can be adjusted.
Adopt computer screen to show the damage instruction
No lid box can be stitch (special order)
suitable for 3-ply 5-ply 7-ply(when use it on 7-ply,customer should order in advance)
adopt 4 servo motor(2 head motor,2 control stitch distance motor)
The whole machine electrical isolation transformer protection device.
Automatic wire feed system, no alarm, 20 kg grail flat wire, to save time.
model |
SDJ-2000 |
SDJ-2400 |
SDJ-3000 |
max paper(A+B)*2 (mm) |
4000 |
4800 |
6000 |
min paper(A+B)*2 (mm) |
1060 |
1060 |
1060 |
A mmMax carton length |
2850 |
2850 |
2850 |
A mmMix carton lengt |
350 |
350 |
350 |
B mmMax width |
1000 |
1200 |
1500 |
B mmMin width |
120 |
120 |
120 |
(C+D+C) (mm)Max paper height |
2500 |
2500 |
2500 |
(C+D+C) (mm)Min paper height |
400 |
400 |
400 |
C(mm) |
560 |
560 |
560 |
C(mm) |
50 |
50 |
50 |
D(mm)Max height |
2000 |
2000 |
2000 |
D(mm)Min height |
150 |
150 |
150 |
(mm)Max tongue width |
45 |
45 |
45 |
mm stitch distance |
30-120 |
30-120 |
30-120 |
stitch No |
1-99 |
1-99 |
1-99 |
speed (pies/mim) |
500 |
500 |
500 |
(T)weight |
2.5 |
3 |
3.5 |
LCL : Normal package is wooden box (size : L×W×H). Wooden box will be fumigated . We use strong export stander wooden box pack all machine ,in this case ,machine can be protected very well.
FCL : Machine is to heavy or big , we can choose full container loading . we use PE Film packing then loading to container .
Others : According to customer’s special request .
1.We need tp test the machine working condition before delivery to customer country.
2.If you need our engineers install and teach you hoe to operate machine, we also can send our engineers to your country, but need you bear all fee, tickets, foods, hotel and salary 120usd/day per engineer.
3.Our machine has one year warranty,during this period, if problems caused by our machine quality, we will change all parts for you by free fee.If any questions,can by email by 24hours,we also help you solve these eoblems.
Q: Are you manufacturer or trading company ? Do you have Import &Export right ?
A: we are manufacturer with more than 30 years experience . we have Imp & Exp license ,we can export machines to you directly .
Q: where is your factory ? How can I visit there ?
A: our factory is located in Dong guang County ,Cang Zhou city , He bei province ,China . It is 2 hours from JINAN international airport by car and 1 hour from Cang Zhou high-speed train station.
Q: what is the payment terms ?
A: (1) TT, 30% as deposit, 70% balance before loading
(2)100% irrevocable L/C at sight .
Q: How about after-sales service process? Can I get spare part easily?
A:when problem occur when machine running , contact our sale manger at once, we will solve problem as soon as possible .we will follow below 3 items.
1. Small parts send by DHL at the top speed. (like thin blade, PLC etc)
2. Middle parts by air at the top speed. (like cut off knife)
3. Big parts by ship at the top speed. (like corrugated roll)
Q: what certificated do you have ?
A: We have CE and ISO certificates .
