5ply corrugated carton making machine /electric heating single facer production line

Item

Products

Model

Unit

Quaiity

1

Hydraulic Reel

Stand

Hydraulic arm, clamping, expandable chuck, pneumatic control paper tention. Including kraft paper feeding trolley and guide rail.

set

2

2

Single facer

DWJ-1400, Vacuum adsorbed paper guiding, Cr-Mo Alloy, roller φ320mm, Pneumatically control the gap between glue roller and corrugated roller, manual glue quantity, auto-glue cycle pump, Frequency control,Universal joint Drive B flute

set

1

3

Feeding bridge

TQ1-1400, single facer drive,  auto-synchronization operation. Electric cardboard alignment,  Adsorption tension control

unit

1

4

Surfacer paper preheater

Roller diameter 600mm,including pressure certificate. Wrap angle 60°-270° electrical adjustment.

unit

2

5

Glue machine

TJ1-1400,Manual adjust glue quantity, pneumatic paper pressing, glue cycle pump, individual drive Glue-coating, External power Mechanical synchronization.

set

1

6

Duplex preheater

DY600-1400, electric preheating area adjustment, Diamenter 600mm.

set

1

7

Double facer

SM1-1400, 600mm×10 pcs heat plate, Intensive pressure roller, electric drive lift, cotton belt, pneumatically tensioned, Manual adjust up and down, Manual adjustment and tension,525mm Main transmission drive, 3meters design part

unit

1

8

Thin blade machine

SFY-1400, 4 blades 6 scores, thin blade paper cutting. Manual sheet change, auto blade grinding, total axial moving, efficiency and auto produce tracking

set

1

9

NC cutoff

NCHQ-1400 servo blade roller cutoff, frequency conversion paper in and out, auto-production tracking; auto-sheet changing, stored lots order

set

1

10

Glue Circulatory system

One unit of the main, vector, storage glue-making system, cycle glue supplying, automatic liquid control

unit

1

11

Air-pressing system

1sets air-press station-9m³/min. 1 set air storage thank-1m³, both of them to making sure the enough and stability air supplying

unit

1

12

Electric system

good components and parts, common electrical control, frequency main power controlling.

unit

1

13

Steam system

independent air supplying, independent directly water supplying, rotating parts and the pipe flexible connection. Without boiler and pipes

unit

1

14

Output part

Right angel output device with computer counting function.

unit

1
