HANGZHOU CANDID I/E CO., LTD located in Rm703, NO346 Qingtai street is a professional company specialize in stationery machine designing, manufacturing and export. Founded in 2004, our machines have been exported to more than 30 countries. Main market including: Asia, Africa, America, East Europe.
Working Process: Raw Material>Mixing>Extruding>Cutting>Packing
Extrude diameter: 10-35mm
Speed: 30-180pcs/min
Mixer motor power: 11kw-4P
Mix total volume: 300L
Extruder power supply and total power: 380V 3.7kw
Packing machine power supply and total power:220V,2.0kw
Vacuum pump motor power: 4KW
Advantages of Plasticine Machine
1. Candid play dough making machine automatic detects materials, when lacks materials is will report alarms.
2. Candid play dough making machine is an intelligent machine, it will automatically to adjust the production speed when lack of raw materials.
3. Screw, cartridge, and material contact surfaces all use China top stainless steel.
4. PLC control panel more easy to control the machine.
Specification of Plasticine Machine
This machine is used for making play dough which is commonly used in school for kids, we have machine could customize different size and color.
It has some features as follow:
With dual frequency conversion control, the bag length cutting no need to adjust so that saving time and material
human-machine interface, setting parameters is convenient.
Self-fault diagnosis, the failures are displayed clearly.
high-sensitivity electric-eye tracking and digital input cutting position makes the sealing and cutting more accurate. Independent temperature controller suitable for various packing materials
According to customer requirement, our professional team could design and suggest most suitable Play Dough Making Machine for them, our offer will cover all the information they may require include mixing machine, extruding machine, packing machine, mold, raw material. We can offer all equipment and material to our customer with high-grade quality and competitive price, that means related play dough making machine, customer could get one-stop service from CANDID.
Meanwhile, CANDID have a professional after-sale team who could guide our customer in their workshop to install the playdough making machine and training their worker until they could operate the machine well, and our team are full of experience in this field and could solve any problem that may occur in the installation.
Total volume 300L
Impeller type Adopt cast steel, covered with 3mm thickness sus304 stainless steel, material contact parts are all of stainless
Main motor power 11KW-4P
Reducer model 4# cycloid reducer
Seal form Seal with other material
Heat method Electric heating rods, heat transfer medium is thermal oil; power: 12KW (4KW*3)
Vacuum pump motor power 4KW
Impeller speed 37/21r/min
Discharging method Screw extrude, power: 3KW;
Screw barrel diameter: 89mm
The gap between impeller and cylinder 3mm
Mixing tank Material contact parts are of sus304 stainless steel
Barrel Made of 5mm thickness sus304 stainless
Side plate 14mm Q235B steel plate complex 3mm sus304 stainless plate
Cover parts Thickness: 3mm, adopt 3mm sus304 stainless steel
