Equipment Description:
Mechanical low-frequency vibration test equipment used to do shock testing for mechanical and electrical and electronic components, communications, equipment, computers and motor vehicles parts, it used to inspect the durability of products or effectiveness of the transport. From that to identify the product quality that tolerate vibration.
Applicable Industry:
Mechanical low-frequency vibration test equipment apply to electronic, mechanical and electrical, optical, communications, computers, motor vehicles, toys, packaging and other industries.
Technical Parameters:
Model |
KJ-4007 Mechanical low-frequency vibration test equipment |
FM range |
5~50HZ adjustable |
Consumed power |
3 HP |
Standard load |
50kg (note: Max load is 70kg) |
Motor |
Use 1HP1:2 motor and 2HP motor to control up and down and left and right |
Max speed |
Divide into 700RPM,700RPM |
Power in |
10HZ |
Starting velocity |
Divide into 150RPM,150RPM 12 |
Work table size |
800×800×20mm, high of fence 100mm |
Amplitude(P-P) |
Amplitude of left and right is 10mm, up and down is 8 mm |
Shock speed |
Up and down is 150~700RPM, right and left 150~700RPM; |
Eccentric Group |
Using 1-inch-ray with 5mm eccentric cam combination |
Body holder |
Fang Tung-inch to manufacture |
Foundation |
using 1.5mm thick electrolysis plate with shock foot to fix |
Boarding |
using electrolysis plate 1.5mm thick (closed screw type, for easy removal and maintenance) |
Crawl |
Using 10mm thick stainless steel with hand-adjusted screw, sliding adjustable? Fixed |
Table board material |
20mm thick aluminum tops |
Table floor support |
Use of airbags fixed |
Main switch |
duplex 15A master switch using Fuji |
Drive style |
Use of direct-drive motor and the crank rod drive upper and lower transported around vibration |
Supply voltage |
220V 50HZ |
Products Show:
Company Show :
Our Customers:
Our Certifictaes:
