General introduction:
The side entrance stainless steel bag filter housing with the construction of side inlet and bottom outlet, that design makes the SS filter housing very easy to wash; optimized design on micron rated filter bag fixing and sealing, woven SS drained basket, screw tight SS bag filter housing cap makes the liquid filter bags with a perfect performance even under the high pressure.
Properties:
a. The SS (stainless steel) bag liquid filter housing with side inlet and removable cap, the solution won’t spillover when opening the filter housing.
b. The Liquid filter housings with screw tight, no need special tools to operate.
c. This SS single bag filter housing with stable and adjustable supporting shelf, easy to installing.
d. The SS bag filter housing with the optimized sealing solution, without leakage under high pressure.
e. The Stainless steel filter housing with sound polishing treatment and SS supporting cage, well protect the filter bags, easy to wash.
f. The SS304 filter housing and SS316 filter housing both can be choosed.
Design available:
Qty of the filter bag(suitable for both traditional and absolute micron rated filter bags): single
Bag size: No.1, 2, 4 and so on, special size can be customized.
Connection size of the SS bag filter housing: DIN/ANSI/BSP/NPT
Material of the liquid filter vessels: SS304 filter housing, SS316 Filter Housings, special material can be customzied.
Sealing ring of the Liquid filter housings:Buna N/EPDM/Viton/Silicon/ FEP+FPM
Application environments of the Stainless Steel bag Filter Housing:
Max. flow of the SS bag filter housing: 40 CBM/hr
(note: testing filter house size: No.2, the actual flow will subject to the filter media and the properties of the solutions as well)
Design operation temperature of the stainless steel filter housing: 150 degree C.
Designed pressure of the liquid filter housing: 10 Bar.
Applicable industries of stainless Steel bag Filter Housings:
a. Painting
b. Electronic industries
c. Electrolyte
d. Silica industries
e. Fine chemicals
f. Paper production
g. Food industries
The typical parameters of the side-in SS single bag industrial filter housings:
