Product Description
KJ-3090B Digital Combined IZOD&Charpy Impact Tester
Introduction:
This impact tester is used to test impact toughness of hard plastic,GFPA,glass fiber reinforced plastics,ceramics, cast stone,electrical insulating material and other non-metal material.It's a ideal testing equipment in chemical industry,R&D institution,quality controlling dept.
Character:
1,This impact tester adopts mico-computer technology to manufacture,it's a intelligentize and digital impact tester.It can correct automatically energy loss caused by friction and wind drag.(After sample breakage,It's one-time finished for checking pendulum bob surplus energy and correcting the energy loss.)
2,This impact tester is used to electronic display to show the test result, test result output by printer.Reading intuitive,improving the accuracy.
3,Adopts rotary encoder grating angular technology,high accuracy,good stability,big measurement ranges.Digital showing impact energy,impact strength,Pr-elevation ,lead angle,average value,energy loss ...
4,KJ-3090 is a combined impact tester, cantilever beam impact test and charpy impact test,designed by IS0 179,GB/T 1043,JB/T 8762 and ASTM D256.
Charpy impact test:
Impact speed |
2.9m/s |
3.8m/s |
Pendulum bob energy |
1J,2J,4J,5J |
7.5J,15J,25J |
Pendulum bob Torque |
Pd1=0.53590Nm Pd2=1.07180Nm Pd4=2.14359Nm Pd5=2.67949Nm |
Pd7.5=4.01924Nm Pd15=8.03848Nm
|
Centre distance |
230mm |
395mm |
Pendulum bob Pr-elevation |
150° |
|
Blade fillet radius |
R=2±0.5mm |
|
Jaw fillet radius |
R=1±0.1mm |
|
Impact blade included angle |
30±l° |
|
pendulum bob impact Energy loss |
1J:2%;2J:1%; 4J,5J:0.5% |
0.5% |
Jaw interval distance |
40mm,60mm, 70mm |
60mm, 70mm,95mm |
IZOD impact test:
1,Temperature:(15-35)℃
2,Impact speed:3.5m/s
3,Impact energy:1J,2.75J,5.5J,
4,Impact moment:Pd1=0.535N·M
Pd2.75=1.4737N·M
Pd5.5=2.9474N·M
Pd11=5.8949N·M
Pd22=11.7898N·M
5,Bob angle:150°±1°
6,Impact center distance:335mm
7,Impact blade fillet radius:0.8±0.5mm
8,Distance from impact blade to jaw:22±0.2mm
9,Outside size:560(Length)* 300(Width)* 840(Height)mm
10,Weight:80KGS
GUANGDONG KEJIAN INSTRUMENT CO., LTD., founded in 2003, is a professional research and development, production of precision testing instruments and provides a complete set of test solution technology enterprises, with professional factory equipment technology research and development team and excellent production, management level, continuously provide customers with satisfactory products and services, and gradually become the industry's leading supplier of instrumentation.
In line with the trend of market globalization, KEJIAN Instruments registered its wholly-owned subsidiary - KEJIAN Industrial Hong Kong Limited in 2009, and began to explore the international market and provide KEJIAN instruments products to overseas customers. So far, KEJIAN instruments has provided high-quality products and services to customers in more than 50 countries and regions around the world, many of which have become long-term partners because of their recognition and trust in KEJIAN instruments.
Based on the recognition of KEJIAN Instruments, The National Standards Drafting Committee invited us to participated in the drafting and revision of a number of national standards, and was invited to attend the adhesive industry summit forum for many times, sparing no effort to contribute to the development of national and industrial technologies.
KEJIAN Instrument Service:
If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-con.
Onsite Service:
1.Device installation
2.Equipment Operation Test Technology training
3. Equipment Calibration
4.Daily maintenance and maintenance of equipment
Free technical training for visiting factories 24-hour Online contact
Free software upgrades
Free information:
1.Product Instruction;
2.Product operation instruction/video;
3.Experiment Test (test application, test report)
Device Problem Handling:
1. Social media 24 hours online communication;
2. Mail Seamless Docking;
3. Video Conferencing;
4. Artificial free door-to-door service.
Fumigated Heat Treating Wooden Package
Ship from Shenzhen Seaport or Shenzhen/Guangzhou/Hongkong by Air
1. Why Choose Us?
(1)Focusing on this testing field for over 15 years makes us professional.
(2)Located in Dongguan city--the world class manufacturing city.
(3)After-sales service for 12 months, promptly deal with all the problems.
2. Are you a factory?
Yes, we are.
3. What's the product delivery time?
Within 10 work days after deposit received.
If we have stock, the delivery time will be greatly shortened.
4. What's your terms of trade?
We accept EXW, FOB, CIF, CNF and so on.
