Color touch screen Plastic mfi index test machine tester
It is not only applicable for the material such as polyethylene, polystyrene, polypropylene, ABS resin and POM resin with low molten temperature, but for polycarbonate, poly-oxide, fluorine plastic, nylon with high molten temperature. It is the ideal instrument for scientific research institutions, factories and enterprises, university institutes, technical supervision, commodity inspection arbitration.
Standard
It conforms to the standards of GB3682,ISO1133,ASTMD1238,ASTMD3364,DIN53735,UNI—5640,JJGB78—94 etc.
Product Description:
|
Barrel parameters |
Inner hole 9.55±0.025mm |
|
Pistons parameters |
Piston head: 9.475±0.015mm |
|
Piston length |
H=6.35±0.1mm |
|
Parameters |
Extrusion hole 1=2.095±0.005mm |
|
Temperature parameter |
With intelligent temperature control instrument, with four pairs of significant temperature setting control, PID parameters can be automatically set, precision up to ± 0.1 degree centigrade |
|
Temperature range |
400℃ |
|
Temperature rating |
±0.2 ℃ |
|
Display resolution |
0.1℃ |
|
Maximum consumption |
< 600W |
|
Temperature recovery time |
less than 4 min. |
|
Weight accuracy |
±0.5% |
|
Basic configuration |
0.325kg, 1.2kg, 2.16kg, 3.8kg, 5.0kg, 10.0kg, 12.kg, 21.6kg |
|
Loop distance from up and down |
30mm |
|
Control precision |
± 0.1mm |
|
Times of cutting the material |
0~10 times |
|
Material cutting interval |
0~999s(set reference Table 2) |
|
Barrel temperature time |
15 min. |
|
Material be installed |
1 min |
|
Material sample temperature recovery time |
4 min. |
|
When binder set |
1min |
Melt Flow Index Testing Machine /melting flow indexer
Melt Flow Index Testing Machine /melting flow indexer
1.After an order is placed, when will you send to us?
Generally about 7 days, If we have it on stock, we can arrange shipment within 3 days.
2.What about the warranty with after - sales services?
12 months warranty. Besides, we can help you to repair your problem controller freely.
3.What about the services and product' quality?
Our products are widely recognized and trusted by users.All the products meet with: ISO, ASTM, AATCC, BS, EN, DIN, JIS and other requireable standards
if you have any question, pls contact us directly.
