cable tv fiber rf 1550nm mini ftth indoor receiver optic node

Performance

unit

Index

FTTH

Optical properties

Receiving optical power

dBm

-15~+2

Optical reflection loss

dB

>45

Light receiving wavelength

nm

1100~1600

Optical fiber connector

FC/APC SC/APC etc. optional

Link characteristic

(C/N)

dB

≥50

(C/CTB)

dB

≥65

(C/CSO)

dB

≥63

RF characteristic

Frequency range

MHz

45~1200

In-band flatness

dB

±0.5(45-550MHz);±0.75(550-750/862/1000MHz)

Output level

dBμV

60~85(±1 dBμV)
