Help CenterTop Selling Low Price 8 Port Fiber 22dbm Ftth Distribution Optical Amplifier Edfa
Related Products
-
Hot Sale Package Carton Plastic Iptv Router Catv Wifi Modem Gpon OnuNegotiableMOQ: 1 -
Wholesale 1550nm Mini Edfa 16 Dbm Aluminum 4 Port Ftth Catv Mini Optical Amplifier EdfaNegotiableMOQ: 1
-
Hot Sale 1310nm 1550nm 2mw Fiber Optic Catv Internal Optical Transmitter Aluminum RJ45 FC/APC or SC/APC 19*11*1.75 47~750(862)NegotiableMOQ: 1
-
Wholesale 1310nm Optic Direct 2mw 3dbm Catv Internal Optical TransmitterNegotiableMOQ: 1
-
Wholesale Low Price 8 Port Fiber Distribution Optical Amplifier EdfaNegotiableMOQ: 1
Parameter |
Symbol |
Min |
Typ |
Max |
Unit |
Wave Length* |
λc |
1530 |
1550 |
1565 |
nm |
Saturated Output Power(1) |
Po |
10 |
------ |
33 |
dBm |
Input Power |
Δλ |
-3 |
------ |
+10 |
dBm |
Noise Factor(2) |
NF |
------ |
4.6@0dBm Input |
5 |
dB |
Output Power Stability |
ΔPo |
----- |
±0.05 |
±0.3 |
dB |
Optical Return Loss |
RL |
45 |
------- |
------ |
dB |
Input Isolation |
ISOi |
30 |
------- |
------ |
dB |
Output Isolation |
ISOo |
30 |
------- |
------ |
dB |
Polarization Dependent Gain |
PDG |
------ |
------- |
0.5 |
dB |
|
Input/Output Optical Connector |
SC/APC |
------ |
------ |
------ |
------ |
C/N |
------ |
50 |
------ |
------ |
dB |
C/CTB |
------ |
63 |
------ |
------ |
dB |
C/CSO |
------ |
63 |
------ |
------ |
dB |
Applications
Analog CATV long distance transmission
For video optical Transmission system
Optical Distribution System
FTTH system
Features
Low noise figure: Typical<4.5dB (0dBm input)
Extremely low CSO distortion:<-70dBc
Dual Power can plug high quality power:220V Mixed interpolation with 48V
High stability and reliability: MTBF>100000 hours
Network management Agent use hot swap
Perfect Network management interface: Ethernet,RS-485 and RS-232
Support Telnet and standard SNMP Network management
High precision AGC/APC circuit: Precision is ±0.05dB
Intelligent Temperature Control System: Power consumption and hot radiation reduce
30% than common products
Flexible mechanical and circuit structure(including pure module, Electric module, desktop and 1U structure)
OEM is available
Compatible with BellcoreGR-1312-CORE
