CATV high power 16 output with 22 or23 dBm 1550nm indoor CATV Optical amplifier EDFA
- 1000 per Month
- T/T Credit Card
You May Like
-
Hot sale indoor toslink shutter transmitter tv ftth pon wdm catv Optical Receiver
-
YaTai high power edfa 16 port 19dbm WDM fiber optic signal amplifier
-
wholesale customized portable normal optical mini fiber optic set catv tool kit
-
wholesale white ftth network epon fiber optic modem iptv catv gpon onu
-
best price customized portable catv normal mobile mini kit optic tool set
-
wholesale customized portable normal optical mini fiber optic set catv tool kit
Product Description
Warranty period of 3 years!!
These products are widely used in CATV transmission system and the high power distributing system FTTH requirement. It can be used for CATV analog/digital signal distribution, or match with PON system to construction the triple network integration. (Triple wavelength WDM is optional)
|
Parameter |
Symbol |
MIN |
TYP |
MAX |
UNITS |
||||||
|
Operating Wavelength |
λc |
1540 |
1550 |
1565 |
nm |
||||||
|
Saturated Output Power Note1 |
Po |
13 |
------ |
33 |
dBm |
||||||
|
Input Power |
Pi |
-3 |
------ |
+10 |
dBm |
||||||
|
Gain |
G |
------ |
------ |
30 |
dB |
||||||
|
Noise Figure Note2 |
NF |
------ |
------ |
6 |
dB |
||||||
|
Output Power Stability |
ΔPo |
----- |
±0.05 |
±0.2 |
dB |
||||||
|
Input Isolator |
ISOi |
30 |
------- |
------ |
dB |
||||||
|
Output Isolator |
ISOo |
30 |
------- |
------ |
dB |
||||||
|
Input Pump Leakage |
PLi |
------- |
------- |
-35 |
dBm |
||||||
|
Output Pump Leakage |
PLo |
------- |
------- |
-45 |
dBm |
||||||
|
Return Loss |
RL |
------- |
------- |
-45 |
dB |
||||||
|
Polarization Dependent Gain |
PDG |
------ |
------- |
0.3 |
dB |
||||||
|
Polarization Mode Dispersion |
PMD |
------ |
------- |
0.5 |
ps |
||||||
|
Operating Temperature |
Tw |
-5 |
----- |
60 |
℃ |
||||||
|
Storage Temperature |
Ts |
-40 |
----- |
80 |
℃ |
||||||
|
Humidity Note |
------ |
10 |
------ |
90 |
% |
||||||
|
Power Supply(1) |
Vps |
170 |
|
264 |
VAC |
||||||
|
Power consumption |
P |
----- |
----- |
50 |
W |
||||||
|
EDFA Pump Power list |
||
|
Port |
Pump power(W) |
Cheap type Pump Power(W) |
|
4 Port |
10w |
5w |
|
8 Port |
20w |
10w |
|
16 Port |
33w |
20w |
|
32 Port |
70w |
33w |
|
64 Port |
100w |
70w |
|
*Don't let the number of pumps go around your purchase, please compare the total power of the pump* |
||
