2021 GRANDE Fully Automatic Juice Filling Production Line 3In 1 and 4 In 1 Various Water Juice Carbonate Filling Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
2002
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Factory Direct Supply Automatic Juice | Water Liquid Plastic Bag Pouch Sachet Filing Packing MachineNegotiableMOQ: 1 -
Grande Automatic Small Beverage Energy Drink Soda Soft Drink Sparkling Carbonated Water Making Filling Bottling MachineNegotiableMOQ: 1
-
Grande 500ML Full Automatic 3 In1 Mini Small Business Bottle Mineral Pure Drinking Water Filling Machine PriceNegotiableMOQ: 1
-
5000 Eggs Incubator Automatic Egg Incubator Diagram Incubator Egg Hatching MachineNegotiableMOQ: 1
-
Grande Widely Used Easy Operation Manufacturing Pastels Chalk Making Machine for SaleNegotiableMOQ: 1
2021 GRANDE Fully Automatic Juice Filling Production Line 3In 1 and 4 In 1 Various Water Juice Carbonate Filling Machine
Products Description
This juice filling line can produce pure water, mineral water, soda water, soft cobonated beverage, beer, juice, various flavoured water, etc.Thisline can be applied to all kinds of plastic machine such as PET, PE, also can design to use glass bottle. It has features of low buying cost, low water and electricity consumption and few space occupation into consideration at the beginning. At the same time it can perfectly complete the function of washing, filling and capping. It improves the sanitary conditions and simplifies the maintenance compared with the last generation filling machine.
Advantage & Technical Parameters
1. The filling line adpots advanced human-machine interface control. High quality international name brand key components.
2. Suspension bottle neck catcher structure allows the machine to change the bottle type easily. By changing the valves, it also can be used for hot filling machine.
3. Spring type rinsing catcher can wash both inside and outside of the bottle.
4. High accuracy pressure water filling mechanism, ensure the height and quatity of the water filling level.
5. Magnetic powered cap device ensures tightness and prevents damage of the caps.
6. Quiet, rotary cap unscrambler will not damage caps. Photoelectric sensor detect missing caps thus eliminating uncapped bottle spillage.
7. Built-in safeguard mechanism which ensures the safety of operator and machines.
8. High efficiency air clean filter system ensures high sanitary requirements.
9. Low overall machine noise.
10. Self-lubricating system imported from America provides continuous smooth operation.
2. Suspension bottle neck catcher structure allows the machine to change the bottle type easily. By changing the valves, it also can be used for hot filling machine.
3. Spring type rinsing catcher can wash both inside and outside of the bottle.
4. High accuracy pressure water filling mechanism, ensure the height and quatity of the water filling level.
5. Magnetic powered cap device ensures tightness and prevents damage of the caps.
6. Quiet, rotary cap unscrambler will not damage caps. Photoelectric sensor detect missing caps thus eliminating uncapped bottle spillage.
7. Built-in safeguard mechanism which ensures the safety of operator and machines.
8. High efficiency air clean filter system ensures high sanitary requirements.
9. Low overall machine noise.
10. Self-lubricating system imported from America provides continuous smooth operation.
Model |
GDFA
8-8-3
|
GDFA
12-12-6
|
GDFA
18-18-6
|
GDFA
24-24-8
|
GDFA
32-32-8
|
GDFA
40-40-10
|
GDFA
50-50-12
|
Washing Head Qty |
8 |
12 |
18 |
24 |
32 |
40 |
50 |
Filling Head Qty |
8 |
12 |
18 |
24 |
32 |
40 |
50 |
Cappiing Head Qty |
3 |
6 |
6 |
8 |
8 |
10 |
12 |
Capacity
(500ml)
|
2000BPH |
4000BPH |
8000BPH |
12000BPH |
15000BPH |
20000BPH |
24OOOBPH |
Installed Power |
2KW |
3.5KW |
4KW |
4.8KW |
7.6KW |
8.3KW |
9.6kw |
Overall Size |
2000*1600*2400mm |
2450*1800*2400mm |
2650*1900*2400mm |
2900*2100*2400mm |
4100*2400*2400mm |
4550*2650*2400mm |
5450*3210*2400mm |
GRANDE MACHINERY offer various solutions for everage packing, we can provide you the machines as follows:
★ 1,000～36,000BPH pure water/ mineral water bottling line;
★ 100～2,000bottles, 3liters~15liters filling line;
★ 1,000～2,000BPH 3/5 gallon filling line;
★ 1,000～36,000BPH tea/juice bottling line;
★ 1,000～36,000BPH milk/dairy bottling line;
★ 1,000～36,000BPH white/red alcohol drink bottling line;
★ 500～18,000cans/H cans beverage bottling line;
★ Blow moulding machine from 1000~9000BPH;
★ Water treatment system;
★ Beverage preparation system;
★ 100～2,000bottles, 3liters~15liters filling line;
★ 1,000～2,000BPH 3/5 gallon filling line;
★ 1,000～36,000BPH tea/juice bottling line;
★ 1,000～36,000BPH milk/dairy bottling line;
★ 1,000～36,000BPH white/red alcohol drink bottling line;
★ 500～18,000cans/H cans beverage bottling line;
★ Blow moulding machine from 1000~9000BPH;
★ Water treatment system;
★ Beverage preparation system;
Machine Details
Complete water/juice filling line includes:
1. Injection molding machine, the function is producing the preforms using PET raw material.
2. Blow molding machine(semiautomatic/automatic) the function of which is producing the PET bottles using preforms.
3. Water purification system, the function of which is purifying the raw water to drinking water.
4. Three in one filling machine, rinsing&filling&capping intergrated in one machine.
5. End-of-line system(semi-automatic/automatic), there are light checker, blow dryer, labeling machine, code printer, packing machine, etc.
Related Top-rated Products
Company Profile
Henan Grande Machinery Co., Ltd. has many years mechanical exporting experience.
We are mainly engaged in the designing and manufacturing of food processing, packaging machine and so on.
We are mainly engaged in the designing and manufacturing of food processing, packaging machine and so on.
We have our own excellent quality control personnel and well-trained skilled workers. And besides production machines, we also provide the solutions including customized design and modification. Our machines have been exported to more than 100 countries, have get through the CE certification and many technology patents.
Remarks:
The following details of water/juice filling line are just for your reference. We can offer OEM service according to your needs. Full project of water filling, juice filling, beer filling lines. Any questions, please feel free to ask us.
