Product Description
1.Application:
This series of paint cowles disperser are widely used in paint,ink,dyeing,pigment,medical and papermaking and other industries.
2.Features:
Minimum included air during mixing and dispersion; Perfect solid-liquid mixing and dispersion effect; And fast dissolution and fine particles during high and medium-speed dispersion process.
3.Main Technical Parameters:
| Models | FS4 | FS5.5 | FS7.5 | FS11 | FS15 |
| Principle power | 4KW/5HP | 5.5KW/7.5HP | 7.5KW/10HP | 11KW/15HP | 15KW/20HP |
| Rotational speed | 0-1500 or 0-3000rpm | ||||
| disc size | Φ150 and Φ200mm | Φ200 and Φ250mm | Φ250 and Φ300mm | ||
| Lifting stroke | 900mm | 1000mm | 1200mm | ||
| Pump power | 0.55kw | 0.75kw | 0.75/1.5kw | ||
| Mixing tank capacity | 200L | 250-300L | 400-600L | 500-600L | 800L |
| Weight | 500kg | 600kg | 800kg | 900kg | 1000kg |
| Models | FS18.5 | FS22 | FS30 | FS37 | FS45 |
| Principle power | 18.5KW/25HP | 22KW/30HP | 30KW/40HP | 37KW/50HP | 45KW/60HP |
| Rotational speed | 0-1500 or 0-3000rpm | ||||
| disc size | Φ300 and Φ350mm | Φ350 and Φ400mm | |||
| Lifting stroke | 1200mm | ||||
| Pump power | 1.5kw | 2.2kw | |||
| Mixing tank capacity | 1000L | 1200L | 1500-2000L | 2000L-3000L | 3000L-5000L |
| Weight | 1100kg | 1200kg | 1200kg | 1400kg | 1600kg |
4.Remarks:
1)Model of FS22kw,FS30kw,FS37kw and FS45kw can be made double shaft dispersers.
2)The above listed mixing capacity is cauculated as per water medium.
3)The disperser we made can be with power of 132kw.
4)Electric control cabinet can be explosion-proof or non anti-proof.
5)The power supply can be customized.
