<hr>china good supplier S-series 3 roll mill for paints and inks>

1.Detailed Product Description:

This series of 3 roll mill are specially applied in polishing the materials with dispersitivity, high viscosity, and fineness.The roller is poured by the chilling cast alloy iron. Crystal close,the intensity is high. The surface has the high degree of hardness and the wear-resisting. It is equipped with the cooling system.We also produce the electric heating,steam heating type 3-rollers mill and each kind of specification 3-rollers mill such as granite roller, ceramic roller, never rusty roller.



The machine effects in polishing through extruding and wearing in three rollers.



2.Main Technical Parameter:

ModelS65S150S200S260S315SM405
Diameter mmΦ65Φ150Φ200Φ260Φ315Φ405
Lengthmm125300500695760810
 Speedslowr/min3225.32019.11915
Midr/min8963.25554.55445
Fastr/min250152155155155135
MotorType YS7144Y100L1-4Y112M-4Y160M-6Y160L-6Y180L-6
Powerkw0.752.247.51115
Speedr/min140014201420970970970
Rotio of speed1:2.8:7.81:2.5:61:2.8:8.11:2.8:8.11:2.8:8.11:3:9
Dimension(L×W×H)mm420×400×440820×800×9201180×1120×9801645×1350×11001720×1550×11802150×1980×1250
Weightkg80500750210028005200

2018 China good supplier S-series 3 roll mill for paints and inks2018 China good supplier S-series 3 roll mill for paints and inks2018 China good supplier S-series 3 roll mill for paints and inks
