9D Copper Rod Big Drawing Machine Rod Brake Down
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Other
Year Established:
1991
Annual Export Value:
Above US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Product Description
|
NO. |
Item |
Parameter |
|
1 |
model |
DL400-9D big drawing machine for copper wire |
|
2 |
inlet dia |
Φ8mm |
|
3 |
outlet dia |
Φ3mm~Φ2.6mm |
|
4 |
Drawing die numbers |
9 |
|
5 |
line speed (max) |
800MPM |
|
6 |
structure of machine |
weld |
|
7 |
Drawing speed |
2t/h |
|
8 |
Area reduction rate of m/c |
23.6% |
|
9 |
capstan reduction rate of m/c |
20% |
|
10 |
capstan |
Tungsten carbide |
|
11 |
capstan dia (max) |
Φ400 |
|
12 |
Fix speed capstan dia (mm) |
Φ400 |
|
13 |
Total power |
160kw,DC motor |
|
14 |
coiling power |
11kw /15kw three phase AC frequency motor |
|
15 |
the way of controlling speed |
AC control +frequency control |
|
16 |
transmission way |
Grinding gear(20CrMnTi Sophisticated helical gear ) |
|
17 |
Pay off way |
Overhead |
|
18 |
Cooling way |
Fully immersed |
|
19 |
service voltage |
Three phase 380V(AC),50Hz |
