Help CenterContinues Big Copper Rod to Small Cold Rolling Mill
Related Products
|
No. |
item |
Parameter |
|
1 |
Model: |
Copper rod cold rolling mill, copper alloy cold rolling mill. Other metal rod cold rolling mill, other alloy cold rolling mill,copper / aluminum continuous casting and rolling etc. |
|
2 |
Input dia |
Φ55mm,Φ35mm,Φ25mm,Φ20mm,Φ17mm,Φ16mm,Φ14.4mm,Φ12.5mm,Φ8mm etc. |
|
3 |
Output dia |
Φ20mm,Φ18mm,Φ17mm,Φ8mm,Φ6mm,Φ5mm,Φ4mm,Φ3 mm etc. |
|
4 |
Outlet rod out of roundness |
No more than 0.2mm after rolling, or more accurate |
|
5 |
Rolling pass |
2-16 or as each customer’s requirements |
|
6 |
Rolling speed |
Max 3M/s for continuous rolling, Max 5M/s for discontinuous rolling. |
|
7 |
Pass schedule |
ellipse-round hole type system or triangular -round type system |
|
8 |
total extend compression ratio |
2-10, or as each customer’s requirements |
|
9 |
each pass compression ratio |
1.15~1.4(hole type can change) |
|
10 |
Total power |
100kw~500kw |
|
11 |
Running mode |
Each frame separate transmission speed controlled by frequency or AC servo |
|
12 |
Operation mode |
PLC control, touch screen display,can improve to DCS control or networking |
|
13 |
type |
2 high horizontal- vertical or 3 high positive triangle-inverted triangle |
|
14 |
nominal roller dia |
Φ200mm(double-groove/multi-groove),Φ248mm(double-groove/multi-groove),Φ264mm,Φ300mm,Φ370mm,Φ400mm etc. |
|
15 |
No. of frame |
2-16 or more |
|
16 |
Main motor |
11kw-110kw AC frequency motor or AV servo motor for each |
|
17 |
roller material |
other imported material etc. |
|
18 |
rolling mill size |
a complete production line: length 18m *width 6 m*height 2.5m Main machine : length 7.6m*width 2.3m *height 2m |
|
19 |
height of center |
height from the ground 1230mm |
