Copper Alloy Cold Rolling Mill

Copper Alloy Cold Rolling Mill photo-1
Copper Alloy Cold Rolling Mill photo-2
Copper Alloy Cold Rolling Mill photo-3
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Other
Year Established:
1991
Annual Export Value:
Above US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Product Description



No.

item

Parameter

1

Model:

Copper rod cold rolling mill, copper alloy cold rolling mill. Other metal rod cold rolling mill, other alloy cold rolling mill,copper / aluminum continuous casting and rolling etc.

2

Input dia

Φ55mm,Φ35mm,Φ25mm,Φ20mm,Φ17mm,Φ16mm,Φ14.4mm,Φ12.5mm,Φ8mm etc.

3

Output dia

Φ20mm,Φ18mm,Φ17mm,Φ8mm,Φ6mm,Φ5mm,Φ4mm,Φ3 mm etc.

4

Outlet rod out of roundness

No more than 0.2mm after rolling, or more accurate

5

Rolling pass

2-16 or as each customers requirements

6

Rolling speed

Max 3M/s for continuous rolling, Max 5M/s for discontinuous rolling.

7

Pass schedule

ellipse-round hole type system or triangular -round type system

8

total extend compression ratio

2-10, or as each customers requirements

9

each pass compression ratio

1.15~1.4(hole type can change)

10

Total power

100kw~500kw

11

Running mode

Each frame separate transmission speed controlled by frequency or AC servo

12

Operation mode

PLC control, touch screen display,can improve to DCS control or networking

13

type

2 high horizontal- vertical or 3 high positive triangle-inverted triangle

14

nominal roller dia

Φ200mm(double-groove/multi-groove),Φ248mm(double-groove/multi-groove),Φ264mm,Φ300mm,Φ370mm,Φ400mm etc.

15

No. of frame

2-16 or more

16

Main motor

11kw-110kw AC frequency motor or AV servo motor for each

17

roller material

 other imported material etc.

18

rolling mill size

a complete production line: length 18m *width 6 m*height 2.5m

Main machine : length 7.6m*width 2.3m *height 2m

19

height of center

height from the ground 1230mm
