2019 Hot Sale Ozone Aging Testing Machine Ozone Aging Test Chamber
Products title
Uses:
Ozone Aging Test Chamber Can be used to test rubber products with static tensile deformation, such as
vulcanized rubber, thermoplastic rubber, cable insulating bush; expose the test specimens to the sealed
air in the test chamber without light and with constant ozone concentration and constant temperature according to
predetermined time, and then observe the cracks on test specimens' surface and the degree of change of other
properties to evaluate the rubber's ozone aging resistance properties.
Design Standard:
GB10485-89 GB4208-93 GB/T4942 and corresponding IEC ISO & ASTM
Character:
- Touch panel controller, simple and friendly menu
- Closed-loop servo control ensures highly stable ozone concentration levels
- Ozone resistant wetted materials
- Castors
Parameter:
|
Model |
|
ROZT-125DMR | ROZT-320DMR |
| Volume | ≥100L/min | ≥240L/min | |
| Number of jig | 8 | 12 | |
| Ozone concentration | 20~250pphm | ||
| Temperature range | (RT+10)~60℃ | ||
| Rotate speed | 20~25mm/sec | ||
| Static stretching rate | 5±1~80±2% | ||
| Dynamic stretching rate | 5±1~30±2% | ||
| Dynamic stretching frequency | (0.5±0.025) time/s | ||
| Internal dimension(CM) | W | 50 | 80 |
| H | 50 | 50 | |
| D | 50 | 80 | |
| Internal dimension(CM) | W | 105 | 135 |
| H | 190 | 200 | |
| D | 88 | 118 | |
| Power | 220V 60HZ(50HZ) | ||
Q:What about your quality?
A:Each equipment must be carry out 100% examination and test again before shipping
Q:What is the MOQ ?
A:Most instruments support MOQ one set.
Q:How long the delivery time ?
A:At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20 working days after deposit receipt. If you are in urgent need, we can consider making special arrangement for you.
Q:How long is the warranty of the products?
A:One year ,but we can provide you life long support .
Q:What is the package?
A:Export standard Solid wooden case
Q:What is the shipping way ?
A:We have stable forwarding agent for air and sea transportation ,and also express about DHL TNT etc , we will suggest you the best shipping way base on your requirement .
Q:What is the payment term ?
A:T/T, L/C,Western Union,Money gram ,Paypal etc
Q:Do you accept customization service?
A:Yes, of course, we can not only offer standard Testing Chamber, but also customized machines according to your request. Don't hesitate to tell us your requirement, we will try our best to meet your needs.
Q:Can we visit your factory before order?
A:Yes, we warmly welcome and sincerely invite you or your team to visit our factory, we will help to arrange hotel and pick up you from airport
