Xenon lamp aging test box is a kind of weather resistance test box. It uses a xenon arc lamp that can simulate the full sunlight spectrum to reproduce the destructive light waves existing in different environments. It provides a corresponding environment for scientific research, product development and quality control.
Sample exposed to the light and heat radiation of the xenon arc lamp to perform the aging test. To evaluate the light resistance and weather resistance of certain materials under the action of the high temperature light source.
The xenon lamp test chamber suitable for testing the quality of electronics, electrical appliances, communications, meters, vehicles, plastic products, metals, food, chemicals, building materials, medical, aerospace and other products
Feature
-
Equipped with a viewing window to facilitate observation of the test process.
-
Equipped with movable pulley, easy to move and save space.
-
Equipped with a filter to protect the lamp to extend the life of the lamp.
-
Equipped with easy-to-install sample rack.
|
Light source |
6.5KW water-cooled xenon lamp |
|
Continuous lighting time |
>2000 hours |
|
Temperature control |
Black panel temp:40~110±2℃,(BST):40~120±2℃ |
|
Humidity control |
Light:10-70%RH±3%,No light:30-95%RH±3% |
|
Irradiance control |
0-1.5W/(340nm),0-3.0W/(420nm) |
|
Cooling device |
Xenon lamp cooling: pure water circulation system, water tank cooling: air cooling |
|
Humidity Method |
Spray evaporation humidification |
|
Water supply |
deionized water,rate of flow 2.1L/min,Pressure:>1.5KG/cm |
|
Test turntable |
three-decker,Standard sample size:150x70x3mm,maximum sample capacity:65pcs,diameter of rotary :640±6mmx1r.p.m |
|
Material of test chamber |
stainless steel |
|
Interior dimension |
(WxHxD)78.5x72.5x78.5cm (can be customized) |
|
External Dimension |
(WxHxD)120x175x120cm (can be customized) |
|
power supply |
3φ 4W+G 220V 60HZ,3φ 4W+G 380V 50HZ 50A |
can be customized as you demand
Q:What about your quality?
A:Each equipment must be carry out 100% examination and test again before shipping
Q:What is the MOQ ?
A:Most instruments support MOQ one set.
Q:How long the delivery time ?
A:At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20 working days after deposit receipt. If you are in urgent need, we can consider making special arrangement for you.
Q:How long is the warranty of the products?
A:One year ,but we can provide you life long support .
Q:What is the package?
A:Export standard Solid wooden case
Q:What is the shipping way ?
A:We have stable forwarding agent for air and sea transportation ,and also express about DHL TNT etc , we will suggest you the best shipping way base on your requirement .
Q:What is the payment term ?
A:T/T, L/C,Western Union,Money gram ,Paypal etc
Q:Do you accept customization service?
A:Yes, of course, we can not only offer standard Testing Chamber, but also customized machines according to your request. Don't hesitate to tell us your requirement, we will try our best to meet your needs.
Q:Can we visit your factory before order?
A:Yes, we warmly welcome and sincerely invite you or your team to visit our factory, we will help to arrange hotel and pick up you from airport
Installation
Training
Calibration
Preventive Maintenance
Technical Support
Relocation Assistance
Upgrade
Repair & Parts
