REALE Rapid temperature change test chamber meet the standard MIL-STD-2164, MIL-344A-4-16, MIL-2164A-19, NABMAT-9492, GJB-1032-90, GJB / Z34-5.1.6, IPC-9701 etc.
REALE Rapid temperature change test chamber have obtain the CE certificate and can be circulated in the European market.
|
Model |
RTP-63 |
RTP-80 |
RTP-100 |
RTP-150 |
RTP-225 |
RTP-408 |
RTP-800 |
RTP-1000 |
|
Internal dimension(W*H*D) |
40*45*35 |
40*50*40 |
40*50*50 |
50*60*50 |
50*75*60 |
60*85*80 |
100*100*80 |
100*100*100 |
|
System |
Balanced temperature & humidity control system |
|||||||
|
Temperature range |
-70°C~150°C (Rapid temperature -55°C~85°C linearly) |
-70°C~150°C (Rapid temperature -40°C~85°C linearly) |
||||||
|
Temperture fluctuation |
±0.5℃ |
|||||||
|
Temperature deviation |
±3.0℃ |
|||||||
|
Temperature chamge rate(℃/min) |
5,10,15 |
5,10,15 |
5,10,15 |
5,10,15 |
5,10,15 |
5,10,15 |
5,10,15 |
5,10,15 |
|
Interior material |
SUS#304 Stainless steel plate |
|||||||
|
Exterior material |
Backed paiting steel or stainless steel(SUS304) |
|||||||
|
Insulation material |
Rigid polyrucethane foam +glass fibre |
|||||||
|
Refrigeration system |
Water cooled or liquid nitrogen cooled |
|||||||
|
Semitight compressor,CFC free refrigerant |
||||||||
|
Heater |
High qcuality nickel chrome heater |
|||||||
|
Blower |
Centrifugal fan |
|||||||
|
Controller |
Color LCD screen in English/Chinese, programing,communicating function |
|||||||
|
Safety devices |
No welding wire switch,compressor overheating and over current protection,over temperature protection, blower overload protection,dry heating machine protector,low water protection,fault warning system. |
|||||||
|
Standard accessories |
One observation window, one test hole(Φ5cm), two sets of test racks, one floodlight, one indicator light, four moving wheels, one humidifying tank, 2 meters of power cord, communication interface |
|||||||
|
Options |
RS-232C,Recorder,Special test hole,Special test rack, clapboard |
|||||||
|
Ambinet temperature |
5°C~35°C |
|||||||
|
Power |
AC380±10% 50HZ 3 phase 4 wires+ground wires |
|||||||
If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-conference. If customers require on-site service, the transport and travel expense shall be borne by customer.
Pre-service
--24 Hours online service for your consult.
--Help choose right model,and a series of service,person,advise.
Middle service
--Give you best offer
--Provide discount for many sets order
--Do customer's request:
--Choose payment term you convienent.
--Promptly production and delivery,inform you in time.
--Can provide invoice value as you like to decrease your tax.
After sale service
--1 year warranty service and all life maintenance.
--Technical Egineer are avalible for oversea trainning.
--Free change for some parts
--Remote control technical consult
--Free installation DVD
--Maintenance plan
