Fully Automatic Karl Fischer Water Content Tester TP-2100

Method of Display
7 inch color touch LCD with English display
Method of Testing
MPU controlled electrolysis(Karl Fischer Coulometric Method)
Rate of Electrolysis
2.4mgH2O/min
Electrolysis Current
Auto-control within 430Ma
Testing Range
0.01ugH2O-200mgH2O
Water Content Range
0.0001%（1ppm）—100%
Sensitivity
0.01ugH2O
Accuracy
Water Content: 2ugH2O-100ugH2O; Deviations≤±1ug,
Water Content: 100ugH2O-1000ugH2O; Deviations≤±2.9ug,
Water Content: ＞1000ugH2O; Deviations≤±0.2%(excluding deviations of sample injection)
Drift Compensation
Auto-control via MPU
Stirring Speed
Adjustable and steerable
End-point Indication
LCD display /output via printing / voice warning / end-point indication light
Data Input
Input via touch screen
Sample Number
Numbered by users
Storage
Infinite storage capacity
Printer
Thermal printer, high-speed, low-consumption, with 44 millimeter-wide paper
Printing Content
ug / ppm / mg/L / sample number /experimenter / date
Calendar/Clock
automatic display and print analyzing time and date
Self-checking
Breakdown self-checking
Special Function
Work independently or connected with laptop or other computers
Power Consumption
＜40W
Dimension
390270190mm
Working Environment
Temperature： 5℃-40℃，Humidity: ＜85%
Power Supply
AC220V±10% 50HZ±2.5HZ
Weight
About 7kg
Liquid
Chemical Industry：alcohols, ethers, esters, alkenes, benzenes, amines, organic solvents, phenols and other organic products
applicable to Karl Fischer Method for determination
Petroleum and Power Industry：Insulation Oil, Transformer Oil, Turbine Oil, etc.
Pharmaceutical Industry ：medicine materials
Pesticide Field：emulsifier
Other Industry：electrolyte of lithium battery
Solid
Various mineral salt, citric acid, explosives, paraffin and other solids with good solubility
Gas
Natural gas, liquefied gas, Freon, butadiene, chloromethane, etc.
1. Powerful Itanium and double CPU; direct A/D conversion of testing electrode data. 2. 7 inch color touch LCD display in English. Function of reagent failure prompt, extending the service time of it. 3. Completely closed titration system avoids direct touch between people and the reagent as well as the influence of environmental humidity. 4. The outer shell is made of high-quality cold-rolled steel plate with electrostatic sprayed surface, anti-corrosion and easy to clean. 5. Auto-control and compensation of electrical current via MCU contributes to quick balance of reagent. 6. Auto-control electrolysis current within 430mA ensures high sensitivity and fast analyzing speed. 7. Preinstalled with cubature (including 3 pieces of formula), statistical calculation (including average calculation, standard deviation calculation and rate of change calculation) and elementary arithmetic, with the advantages of auto-analysis and calculation. 8. Automatically tests the sample, analyzes and displays results, and calculates the average value of several times of test. 9. Infinite capacity of results storage is convenient to consult previous testing data whenever necessary. 10. Automatically calculates and prints the following content: ug / ppm / percentage / mg/L / sample number / experimenter / testing date, etc. 11. Network management available by connection with laptop or computer communications through USB or RS232 interface. 12. Multilanguage display available. The program of tester can be upgraded accordingly if related national standard is revised.
